Powerful EFAN IFR 16340 3.2V 400mAh LiFePO4 Rechargeable Battery

Name: Powerful EFAN IFR 16340 3.2V 400mAh LiFePO4 Rechargeable Battery
Brand: EFAN
SKU: 129696219
Availability: InStock

Negotiable MOQ: 10 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

EFAN

Model Number:

16340

Shenzhen Yi Fang Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name EFAN

Model Number 16340

Type Li-Ion

Nominal Voltage Other, 3.2V

Size Other, 18*65mm

Nominal Capacity 400mah

Specifications

1. High quality
2. low inner resistance
3. Safety, high energy density
4. Long life cycles>=2000
5. Cost performance

Basic Information of IFR16340 Lithium Cell>>

Nominal Capacity	400mAh	Cell Configuration	cylinder
Mimimum Capacity	390mAh	Internal Impedance	120mΩ
Nominal Voltage	3.2V	Dimensions(mm)	16.4mm(dia.)*34.4mm(ht.)
Discharge Cut-off Voltage	2.0V	Weight	15 g
Charge Cut-off Voltage	3.65 V	Charge Temperature Range	0°C~45°C
Standard Charging Current	80mAh	Discharge Temperature Range	-10°C~60°C
Standard Discharge Current	80mAh	Charge Method	CC/CV
Fast Charging Current	400mAh	Storage Temperature Range	Less than 1 year:-20~25°C
Fast Charging Current	400mAh	Storage Temperature Range	Less then 3 months:-20~40°C
Max Discharging Current	1200mAh	Cycle Life (80% DOD)	>=2000 cycles
Maximum Continuous Charge Current	1C	Maximum Continuous Discharge Current	3C
