Specifications
1.1.2m T8 freezer LED tube2.LED freezer tube
3.Operate from -40 degrees to 50 degrees
4.TUV,SAA,CB,LED tube
Specifications
T8-03-12-00 (1.2m T8 freezer LED tube)
LED freezer tube
Operate from -40 degrees to 50 degrees
>100lm/W
TUV,SAA,CB,LED tube
1.2m T8 freezer LED tube light (Operate from -40 degrees~ 50 degrees ) with TUV,SAA,CB,C-Tick certificates,
Perfect choice for environments with extreme climates.
Supply for the second largest fridge maker in European market
Features / Advantages :
- 180° Rotating and lockable end caps
- Operation : -40°C ~ 50°C , perfect for environments with extreme climates.
- Humidity Range Operating : 20 % to 90 % , perfect choice for Humid environment
- Lighting efficiency > 100lm/W
- Power efficiency : 90%
- Single End Power Wiring-Safe Application
Technical Specification :
| Item | T8-03-12-00 |
| Dimension | 1198x26mm |
| Input Voltage | AC85-265V 50/60Hz |
| Power | 16W |
| Light Source | Epistar SMD3528 |
| LED quantity | 204pcs |
| Light Output | 1600lm |
| Color Temperature | 2800-3500K, 4000-4500K, 5500-6500K |
| Beam Angle | 120 degrees |
| Color Rendering Index | >80 |
| Power supply efficiency | >90% |
| Lighting efficiency | 100lm/W |
| Power Factor | >0.9 |
| Total Harmonic Distortion | <15% |
| IP Rank | IP44 |
| Certificate | TUV,SAA,CB,C-Tick, PSE,CE,RoHS |
2). Environmental :
Temperature Range Operating |
-40°C to 50°C |
Humidity Range Operating |
20 % to 85 % |
Temperature Range Storage |
-40°C to 80°C |
Humidity Range Storage |
20 % to 90 % |
Dimension (Unit :mm)
Application :
Warehouses
Fridge lighting
Supermarkets
Replacement for conventional fluorescent tubes
Hotels
Conference/meeting rooms
Factories
Offices
Commercial complexes
Residential/institution buildings
Schools, colleges, and universities
Hospitals
Subways
Railway Stations
Airports
Installation :
Equipment :
Packing:
| 0.5m T8 LED freezer tube | 25pcs/carton, Carton size (LxWxH): 505*240*240mm, G.W. : 7.kgs/Carton, With Fragile Mark outside |
|||||||||||||
| 0.6m T8 LED freezer tube | 25pcs/Carton, Carton size (LxWxH): 690*240*240mm, G.W.: 10.75 kgs/Carton, With Fragile Mark outside. | |||||||||||||
| 0.9m T8 LED freezer tube | 25pcs/Carton, Carton size (LxWxH): 996*240*240mm, G.W.: 13.77kgs/carton ,with Fragile Mark outside | |||||||||||||
| 1.2m T8 LED freezer tube | 25 pcs/Carton, Carton size (LxWxH): 1295*240*240mm, G.W.:18.02 kgs/Carton, With Fragile Mark outside. | |||||||||||||
| 1.5m T8 LED freezer tube | 25 pcs/Carton, Carton size (LxWxH): 1590*240*240mm, G.W.: 22.12 kgs/Carton, With Fragile Mark outside. | |||||||||||||
