| TK-16128 | Incoming CO Line | Local Station | Hybrid Extension | Operator |
| Capacity | 8,16 | 8,16 ~128 | 0 | 2 |
Receiving Call Features |
| Making Call Features |
| * DISA Auto-attendant | * Call Barge In | |
| * Music on Hold | * Least Cost Route | |
| * Operator Attendant | * Intercom Calling | |
* Call Pickup - Ramdonly Pickup - Group Pickup
| * Outside Calling - Dial "0" - Select Desired CO Port | |
* Caller ID to Operator - Intercom - After transfer
| * Call Forwarding - All - On Busy | |
| * Call Transfer | * Class of Services | |
| * Do Not Disturb (DND) | * Dial "9" to Operator | |
| * 3-party Conference Call | * Broadcast | |
| * Day/Night Service | * Exclusive Line | |
| * Setting Operators | * Conversation Duration Control | |
| * CO Line Ringing Assign | * CO Line Group | |
| * Extension Group | ||
| * Extension Lock | ||
| ||
| System Features | Optional Features | |
| * Expandable | * 110V or 220V Transformer | |
| * Self-report Extension Number | * UK/US/AU/EUR Plugs | |
| * 3-class Lightning Protection | ||
| * Ground Connection | ||
| * OGM Record via PC / Telephone | ||
| * Extension Flexible Numbering | ||
| * Date/Time Setting | ||
| * Flash time Setting | ||
| * Remote Program | ||
| * PC Program Billing Software - hotel | ||
| Item | Parameter |
| Power | AC110 or AC220V 50-60Hz |
Power Consume | ≤ 20VA |
| Feed Currency | DC48V, 20~30mA |
| Distortion | ≤ 10% |
| Ringing Currency | AC70V ±10%, 50hZ |
| Voltage Proof | 50hZ, 1000Vrms/ minute |
| Operators | max. 2 |
| DISA | 30second, 3-duration, 15s-7.5s-7.5s |
| Class of service | 7-class |
| Extension digit | 100~999 |
| Flash Time | 300-2000ms |
| Lightning Protection | 3-layers (20k) |
| Caller ID | FSK,DTMF |
We are top 3 manufacture in Communication & parts, PBX system in China since 10 years ago, sharing 25% local market with less than 1% fail rate.
Packing By Export Carton:
1- OUTSIDE PACKING:
Carton Size: 57.5*44*46cm
Qty: 2pcs/ carton
G.W: 33kg/ carton
2- SINGLE GIFTBOX PACKING:
Giftbox Size: 50*36*27cm
G.W: 16kg/ piece
Power Plug Options:
Q: Any type of Telephone can connect your PABX ?
A: Yes,can connect and program it. But some few telephones may can not display Caller ID.
Q: What is auto-attendant ?
A: Auto-attendant (or automated attendant) is a term commonly used in telephony to describe a voice menu system that allows callers to be transferred to an extension without going through a telephone operator or receptionist. The auto-attendant is also known as a digital receptionist.
Q: What is expandable PABX ?
A: The system basically is at smaller capacity, when your company become bigger with more emploees, you can buy add-on cards to add in basic PBX by screw, to make the PBX capacity more big.
Q: Can we buy only sample ?
A: Yes. Can test small orders.
Q: What is Remote Program ?
A: When users forget password or do not know how to configure PABX, we can help from remote factory.
Q: How if I forget the system password ?
A: Please contact dealer or factory for a supper password recover.
Q: Are you trading company or factory ?
A: We are serious factory with self-owned SMT assembly machine. 25% market share in China with brand Lidason.
Q: Where I can get manuals operation/technical data etc?
A: Pls. go to our Download center in our miracall main website,or email to our sales department
