Specifications
easily to heat and insulate.Can make any shapes according to your requestsAuzhan's cartridge heater is made of MgO powder or MgO tube, ceramic cap, resistance wire(NiCr20/80),High temperature leads, seamless stainless steel sheath(304,321,316,800,840). usually in tube form, that is used in heating applications by way of insertion into metal blocks via a series of drilled holes. Cartridge heaters are manufactured in two basic forms - high density and low density.
Cartridge heaters are used to heat plastic injection moulds, dies, platens and so forth, whereas low density cartridge heaters are more suitable forpacking machinery, heat sealing, labelling machines and hot stamping applications.
Technical Specification:
1.Sheath material: SUS304,321,316,Incoloy800,840
2.Wattage Tolerance: +5%, -10%
3.Resistance tolerance: +10%, -5%
4.Voltages available: 380V,240V, 220V,110V,36V,24V or 12V
5.Max operating temp: 800ºC
6.Length tolerance: ±1 mm
7.Diameter tolerance: -0.02mm
8.Standard Cold Zone: 5-10mm;
9.Delivery time: 7-10 working days.
10.Thermocouple Location: type J or K are available
11.Insulation resistance (cold): ≥ 500 MΩ;
12.Maximum leakage current (cold): ≤ 0.5 mA;
When you inquire the cartridge heater, please specify the following details:
1.Tube diameter;
2.Tube length;
3.Tube material:stainless steel304 etc.
4.Lead wire:20cm/1.5m/2m/3m etc.
5.Thermocouple attached is availabe if you need.
