Help CenterSelf-lock Stainless Steel Cable Ties
US$ 0.04 - 1
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Highsail or OEM
Model Number:
HS-4.6x100mm etc
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
201 304 316 Stainless Steel Cable TiesUS$ 0.04 - 1MOQ: 100 Pieces -
12VDC Tomasetto Solenoid CoilUS$ 2.3 - 3.8MOQ: 50 Pieces
-
Red Black CNG Solenoid Valve Coil 12VUS$ 2.3 - 3.8MOQ: 50 Pieces
-
Types Of Solenoid CoilUS$ 2.3 - 5MOQ: 50 Pieces
-
Red Black Automotive Spray Rail Track CoilUS$ 2.3 - 3.8MOQ: 50 Pieces
Place of Origin
Zhejiang, China
Brand Name
Highsail or OEM
Model Number
HS-4.6x100mm etc
Type
Self-Locking
Material
Steel
self-lock stainless steel cable ties
Product Description
Detailed Informations:
| 1.Material |
Stainless steel type: 201 & 304 & 316 Coating:Nylon / Epoxy / PVC |
| 2.Common size | 4.6x100 ~ 4.6x1300mm; 7.6x150 ~ 7.6x1100mm; 12x200 ~ 12x1200mm |
| 3.Width | 4.6mm / 7.9mm / 12mm |
| 4.Length | Length between 100 and 2500mm is available. |
| 5.Thickness | 0.25mm / 0.3mm. |
| 6.Authentication | DNV;CCS;ABS;CE;RoHS;ISO9001. |
| 7.Color | Natural Color;other colors are available. |
| 8.Operating Temperature | -80C°~500C°(-112° F~932° F). |
| 9.Feature |
1):Effective way of securing cable; 2):Unique self-locking mechanism,easy and quick application; 3):High tensile strength; 4):Non-flammable; 5):Heat-resisting,alkali acid,erosion resistant,not apt to age. |
| 10.Application | Stainless steel cable ties are particularly useful in applications where corrosion, vibration, general weathering, radiation and temperature extremes are a concern.installed indoors, outdoors, or underground if necessary. |
| 11.Company Type | Factory/Trading Company,OEM and ODM are welcome. |
Technical Parameters
Ball-Lock 4.6mm and 7.9mm series Stainless Steel Cable Tie Parameter:
(Other types parameters please consult me)
| Item | Length | Wide | Thickness | Max Bundled | Item | Length | Wide | Thickness | Max Bundled |
| L(mm) | W(mm) | mm | E(mm) | L(mm) | W(mm) | mm | E(mm) | ||
| HS-4.6×100 | 100 | 4.6 | 0.25 | 22 | HS-7.9×100 | 100 | 7.9 | 0.25 | 35 |
| HS-4.6×150 | 150 | 4.6 | 0.25 | 35 | HS-7.9×150 | 150 | 7.9 | 0.25 | 50 |
| HS-4.6×200 | 200 | 4.6 | 0.25 | 50 | HS-7.9×200 | 200 | 7.9 | 0.25 | 65 |
| HS-4.6×250 | 250 | 4.6 | 0.25 | 65 | HS-7.9×250 | 250 | 7.9 | 0.25 | 82 |
| HS-4.6×300 | 300 | 4.6 | 0.25 | 82 | HS-7.9×300 | 300 | 7.9 | 0.25 | 90 |
| HS-4.6×350 | 350 | 4.6 | 0.25 | 90 | HS-7.9×350 | 350 | 7.9 | 0.25 | 105 |
| HS-4.6×400 | 400 | 4.6 | 0.25 | 105 | HS-7.9×400 | 400 | 7.9 | 0.25 | 130 |
| HS-4.6×450 | 450 | 4.6 | 0.25 | 130 | HS-7.9×450 | 450 | 7.9 | 0.25 | 140 |
| HS-4.6×500 | 500 | 4.6 | 0.25 | 140 | HS-7.9×500 | 500 | 7.9 | 0.25 | 162 |
| HS-4.6×550 | 550 | 4.6 | 0.25 | 162 | HS-7.9×550 | 550 | 7.9 | 0.25 | 185 |
| HS-4.6×600 | 600 | 4.6 | 0.25 | 185 | HS-7.9×600 | 600 | 7.9 | 0.25 | 190 |
| HS-4.6×700 | 700 | 4.6 | 0.25 | 205 | HS-7.9×700 | 700 | 7.9 | 0.25 | 205 |
| HS-4.6×750 | 750 | 4.6 | 0.25 | 223 | HS-7.9×750 | 750 | 7.9 | 0.25 | 223 |
| HS-4.6×800 | 800 | 4.6 | 0.25 | 235 | HS-7.9×800 | 800 | 7.9 | 0.25 | 235 |
| HS-4.6×850 | 850 | 4.6 | 0.25 | 250 | HS-7.9×850 | 850 | 7.9 | 0.25 | 250 |
| HS-4.6×900 | 900 | 4.6 | 0.25 | 260 | HS-7.9×900 | 900 | 7.9 | 0.25 | 260 |
| HS-4.6×950 | 950 | 4.6 | 0.25 | 272 | HS-7.9×950 | 950 | 7.9 | 0.25 | 272 |
| HS-4.6×1000 | 1000 | 4.6 | 0.25 | 290 | HS-7.9×1000 | 1000 | 7.9 | 0.25 | 290 |
| HS-4.6×1050 | 1050 | 4.6 | 0.25 | 300 | HS-7.9×1050 | 1050 | 7.9 | 0.25 | 300 |
| HS-4.6×1100 | 1100 | 4.6 | 0.25 | 310 | HS-7.9×1100 | 1100 | 7.9 | 0.25 | 310 |
| HS-4.6×1150 | 1150 | 4.6 | 0.25 | 320 | HS-7.9×1150 | 1150 | 7.9 | 0.25 | 320 |
| HS-4.6×1200 | 1200 | 4.6 | 0.25 | 330 | HS-7.9×1200 | 1200 | 7.9 | 0.25 | 330 |
