TJ-61 Magnetic stripe card mounted magnetic machine bank passbook printer magcard and bankbook.

Specifications

Automatic print magnetic strips for credit card,vip card or bankbook,etc.
Quality / Safety Certification: ISO9001: 2000;CE

 TJ-61 Magnetic stripe machine for magcard and bankbook.



1.Product parameters:



Quality / Safety Certification: ISO9001: 2000;CE



Through simple positioning adjustment, can satisfy the magnetic stripe heat press working of the single, double and unfolded bankbook, and the different materials,thickness and specifications.



2.Technical parameters:



Power	220V 50HZ
Main motor power	180W
Speed	18m / minute
Heating power	1000W
Rolling film power	25W
Mold width	16mm or 20mm
Pressure	0.6-0 .8 Mpa
Max. magnetic stripe width	220mm
Min. magnetic stripe width	70mm
Stamping head stroke	80mm
Way of work	continuous rolling
Weight	180Kg
Dimensions	1660 * 950 * 1530mm
Temperature range	Room temperature~299°



3.Advantages:



1. Computer control,easy operation.

2. Air supply combined with motor, powerful pressure,stable temperature,adjustable speed.

3. The rubber roller and steel sheet rubber roller press wheel transmission mode.

4. Automatic aligning, avoid appearing the defect of  intermission and overlap.

5. Compressed air cools after processing, working speed is faster, the effect is better.



Note:We can customize various hot stamping machine by customers’ practical

demand.

Self-priming  automatic feeding raw materials , professional customizing for our clients.





4. Samples show:
