LC-FC OM3-DX-3m Optical Fiber Patch Cord

Specifications

LC-FC OM3-DX-3m Optical Fiber Patch Cord
Insertion Loss low 0.20 dB;
Return loss low -50 dB;
Fiber Type:9/125 Corning fiber

LC-FC OM3-DX-3m Optical Fiber Patch Cord

Fiber Type : OM3  50/125  Corning fiber  Operating Wavelength: 850 nm

Connector Type Polishing :  SC/UPC  SC/APC  FC/UPC FC/APC D4 MU  DIN   ST/UPC   E2000/UPC  E2000/APC  SMA  ESCON MTRJ

Fiber Cable Jacket Type: PVC /LSZH   Simplex/ Duplex   3.0mm/ 2.0mm/0.9mm

Insertion  loss  ≤0.20dB,

Return   loss        UPC≥50 dB,  APC≥60 dB

Radius of curvature       nm   10 ≤ r ≥25

Curvature eccentricity    um   <50

Fiber core  undercut     nm   <50

Insertion loss change< 0.1,Return loss change< 5, No flab, No distortion

Repetitiveness (dB):       Insertion loss change<  0.1,Return loss change< 5

Insert & pull out    :      Max: 2KG

Tensile strength      dB   0-    10KG per minute

Highlights:

1. 10Gigabit Ethernet capable laser-optimized multimode fiber
2. Low cost ,reliability performance
3. Provide high performance

4. High quality of ceramic ferrules
5. High credibility and stability , good in repeatability and exchangeability
6. Compliance with ROSH’s request

Fully tested cables to ensure superior quality and durability

RoHS Compliant



Features:

Low insert loss; Good repeatability; Good changeability; Good temperature stabilization.



Mechanism Features: insert and pull frequency > 1000; Changeability(db) ≤ 0.20Tensile strength < 0.1; Ascillating  test < 0.1.



Condition Features: High temperature < 0.2; Low temperature < 0.2.



Use: Applied in optical fiber communications system, fiber optic data transmission, LAN, optical fiver sensors and optical CATV.



  Parameter:

Description	LC-FC OM3-DX-3m Optical Fiber Patch Cord
Item NO.	Test Item	Unit	Standard & Requirement
1	Appearance	/	No crack, No scar, good conformability
2	Ferrule polished end	/	No scar, No spot
3	Insertion loss	dB	SM≤0.2,
4	Return loss	dB	APC≥-60 PC≥-50
5	Curvature eccentricity	um	<50
6	Fiber core undercut	um	-<50
7	Fall apart test	dB	H=1M,connector free-falling 5 times Insertion loss change< 0.1,Return loss change< 5,No flab, No distortion
8	Repetitiveness	dB	Insertion loss change< 0.1 Return loss change< 5
9	Insert & pull out	/	Max: 2KG
10	Tensile strength	dB	0- 10KG per minutes Insertion loss change< 0.1,Return loss change< 5,No flab, No distortion
11	Addition	dB	2.5Kg,200times,10times/minutes,±80° Insertion loss change < 0.1,Return loss change< 5, No flab, No distortion
12	Package	/	Clean, Correctitude, No dirt
13	Allowable bending radius	mm
