Fiber Optic Splice Closure

Specifications

  Fiber optic splice closure

We can supply u different kinds of optical fiber enclosure:

Belong to Open style mechnical-press sealing tie-in system, widely applied to telecommunication. Network system, CATV, optical cable network system, can through, embranchment. The body adopts high-powered engineering plastic, advanced structure, dexterous and reliable tightness and anti-lighting strike characteristics, suitable for aerial, duct and indoor installation

Technical criterions:
Mechanical intensity: Excellent capability to withstand quake, pressure, stretch. Strong and durable. Close the case and inflate inwards to 0.1 MPa, the Fiber Optic Closure can to bear 1000N axial pulling force and there is no damage and leak gas.
Environment capability: It can operate smoothly in temperatures varying from -40(0C)-+60(0C). Innovative waterproof elastic entire sealing
Sealing performance: After being inflated to 0.1MPa, the case is soaked in the container full of normal temperature water for 15 minutes. There is no bubble emitting.
Insulation resistance: The resistance of insulation between the supporting of metal and the ground is bigger than 2*10, 000MΩ
Service life: All major components in the Closure are designed for 30 years service life.

Size: 435*220(mm)

Application:

Air, ground burying, conduit
Weight: 3.1kg
Material: ABS
Structure: SEAL
Cores: maximun 240cores
