Specifications
1.less energy consumption2.save labor
3.easy to operate
4.installation&workers training included
5.best quality
Huaxian Xinfeng 2013 palm oil processing machine
1. Main parts
(1) Solvent pumps: continuously spray solvent to the rotary-type extractor
(2).Roary extractor: Spray and soak the pre-pressed cake with solvent so that oil fats can be dissolved in solvent(form miscella). After processing, you can get wet meal and miscella (mixed oil).
(3). DTDC: usd to separate the solvent from the wet meal.
(4). Miscella tank 1st: pump the miscella (oil with solvent) in to the miscella 1st , and then add 10% saline water
to it. The phospholipid and impurities in the miscella will react with the saline wter, at last the reactant precipitate,
reaching the goal of purifying.
(5). Miscella tank 2nd: the purified miscella will be pumped into it.
(6). Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be discharged to
condenser for recycling.
(7). Condensers: used to cooling the solvent gas separated from the wet meal and miscella for recycling.
2. Solvent extraction process:
Towline Extractor Advantages:
1) The material is divided into several independent units on the material bed, which can effectively prevent
miscella at all levels from fleeing hither and thither on the material layer and ensure the concentration gradient
between several sprays.
2) Immersion area appears in each lattice, which can help achieve better immersion effect.
3) The chain box is supported by track and can prolong the service life of screen deck by not touching it.
4) The towline extractor is driven by world leading double-shaft hydraulic motor, with balance force, reliable operation and less maintenance cost.
5) Specialty suitable for the extraction of high oil and high power materials, and better immersion effect can be
expected for ordinary oil plants.
3.Negative pressure evaporation process
The liquid from the extractor is the miscella containing grease and oil, which can be separated out
according their different vaporization temperatures. Our company mainly uses vacuum evaporation
technology, and it can reduce solvent leakage and consumption. The separated solvent vapour is cooled
and recycled back to the extractor for reuse, which can improve the solvent efficiency.
4. Advantages
(1) High oil yield , obvious economic benefit .
(2) Residual oil rate in the dry meal .
(3) Improving the quality of the meal .
(4) Low processing cost , high labor productivity.
WE have our own technical team, we could design the project according to
your need, or if you have any special request of the equipment, pls contact us freely!
