Specifications
1.peanut oil solvent extraction machine2.new design
3.save energy
4.low cost
5.good qulity oil
Huaxian Xinfeng 2013 new technology 20T/D Peanut Oil Refinery machine
The Flow Chart of Solvent Extraction
Alkali hot water
Crude oil→filter→mix→reactor→mix→reactor→centrifugal separation→oil residue
↑ ↓
Phosphoric acid hot water→mix ↓
↓
degumming oil←cooler←dry←centrifuge separation←mix←alkali liquor
↓ ↓
↓ vacuum steam jet pump←steam citric acid
↓ ↓
bleaching earth→mix→decoloring→filter→decoloring oil→mix→heat
↓
refined oil←filter←cool←deodorizing←vacuum
Main Processes Introduction
Degumming part
Continuous soap section
Vacuum drying stage
there is still moisture in the oil from the wash separator, and the moisture will affect the stability of the oil. So
the oil at 90°Cshould be sent to vacuum drier to remove the moisture, and then the dehydrated oil goes to the
decoloring process. Finally, pump out the dry oil by canned pump.
Bleaching pot:
Also named bleaching, dewatering pot,it removes water from oil by vacuum.The bleaching earth is
breathed into bleaching pot ,after stirring,filtrated by filter and change the color of the oil.
Decolorization section
Vertical blade filter machine:
Equipped with vertical leaf filter to remove used bentonite from the oil, operating conveniently and continuously ,
low laboring tense, keeps environment well, keeps oil residence in deposable bleaching earth in low level.
Vertical Blade Filter Machine
Deodorization pot:
It uses USU 304 stainless steel plate, under the vacuum condition of vacuum and high temperature
(220-240°C), The deodorization system can remove fatty acid and other rare delicacy high efficiently .make
Meanwhile, the pot has the advantage of lowering steam consuming and avoid of the hydrolyzation of
oil;
Deodorization Pot in Malawi
