Fully automatic car wash system

Specifications

1 110Bar,2200W,230V
2 Copper pump head
3 Cold water clean
4 Upright design with big wheels
5 Clean car,pool,wall,floor..

Parameter

• Type-HB5/11C
• Voltage-220-240V,50HZ
• Power-2200W
• Pressure-110Bar
• Rotation Rate-2800Rpm
• Water Flow-8.6L/Min
• Water Temperature- 0-60°C
• Machine Size-360*375*925mm



Standard Accessories

1 A stainless steel high pressure gun





2 Another option is short gun



3 10 meter high pressure hose –the inner material is threadlike stainless steel that resist to rub.



4 A filter -prevent the inlet pipe from jamming by inclusion in water.







5 Nozzle with varying spray







• Low pressure shape that ideal for spraying herbicides and pesticides for grass,tree, Can also be used for spraying cleaning detergents.
• Fan shape that ideal for cleaning car,bus,window,pool…
• 0 °shape – used for cleaning substance that is very dirty.





Product Characteristic



1 Automatic

Start trigger of high pressure gun  equals to start machine ; Close trigger of high pressure gun equals to close machine. Other machines in market need hold the gun and go back to turn off switch on the machine if you finish cleaning.







2 Save water, Save electricity







3 Best quality

 All seals ring are imported from Germany Parker company.USA microswitch.Copper pump head .







4 The thermal protective system in electric motor  is imported from professional manufacture in German. The machine will automatically stop if temperature reach to 180degree.











5  Unusual design of electric motor and pump head

• Electric motor is in the above of pump head that can protect pistons from dashing of water.







6 Cooling fan resist to overtheated air



• Clean cooling air guarantee long-time normal operation
• Long service life,powerful,energy conservation .







7 Big wheel



• To enhance the flexibility of the machine,The machine can be moved and cross barrier easily.







8 Machine have suck detergent function.

•  Put small white pipe in to detergent and open suction button( the second button of the picture ) then machine begin to work

















Application











high pressure foam gun : directly connect to car washer machine .have spray foam and cleaning function .
