Full Automatic Phenolic Foam Board Making Machine

Specifications

Phenolic foam board machine
1.phenolic foam baord core thickness is: 20-100mm;
2.width: 1200mm;
3.length can be any size.

Full-automatic phenolic foam board making machine/production line



Xuelong phonelic foam board production line can produce the phonelic foam board as the middle core and upper and lower side are aluminum foil, nonwovens, paper and so on. The phenolic foam board  core thickness is: 20-120mm, width: 1200mm, length can be any size according to customers' requirements.



Main technical  parameters:

1)phenolic foam board thickness:20-120mm

2)aluminum foil thickness:0.06-0.12mm

3)density :50-65kg/m3

4)laminated length:24m

5)productivity of phenolic foam board  machine:1-4m/min

6)standard phenolic foam board size: 4000*1200mm(l*w)

7)dimeension of phenolic foam panel machine:45920*5365*3636mm

 Phenolic foam board making machine /production line picture as follows, please check, if you're interested in our machines, contact us  epsmachineatxuelongqiyedotcom .



 A pre-mixing device



B pre-mixing device





Low pressure pre-expander (Phenolic  mixture storage tank and curing agent storage tank)





Phenolic foam board making prduction line-----Laminating coneyor main machine







Locking mechanism on the phenolic foam lamiating coveyor main machine





 Reducer on the laminating coneyor main machine to control the opening height of between the upper and lower chain plate







Stroke sensor switch --to control the distance between the upper and lower chain plate





Temperature sensor on the phenolic foam laminating convyor main machine to control the hot air temperature to produce excellent phenolic foam board.







Uncoiler------ loading the non-woven fabric for the phenolic foam board production



Trimmer : the finished phenolic foam board width is 1220mm, after trimming the width will be 1200mm





Auto-tracking cutting machine







Phenolic foam board making machine/production line equipment layout
