Sinotruk HOWO 40ft 50T Flat Bed Semitrailer for sale

Trailer Model

40ft flat bed Semitrailer

Overall Dimension(Lx W x H)(mm)

12500*2500*1800

Function

transport merchandise, like juice packs, rice etc.

Thickness(mm)

Bottom: 3mm, Side: 1.5mm

Loading Weight( KG)

50000

Axle Brand

Fuwa

Axle Number

Three

Suspension system

Standard Mechanical suspension

Steel Spring

10/10/10 leaf spring suspension

The material of Main beam

The height of the beam is 500 mm, upper plate is 14 mm,down plate is 16 mm,middle plate is 8 mm.

Tire Type and quantity

12R22.5, tubeless tires.

Traction Pin

90mm or 50mm

Spare Wheel Bracket

2 pieces

Tool Box

1 Standard

Landing Gear

Standard brand 28ton external

Brake system

Dual Line braking system

Brake air chamber

Six big double air chamber

Electrical system

1. Voltage: 24v   2. Receptacle: 7 ways (7 wire harness)

Tail lamp with turn signal, brake light & reflector, side lamp etc.

One set 6-core standard Cable.

Side Guard

According to customer’s requirement

Painting

Color can be choose

Packing

Polish with wax before shipping
