Specifications
1.industrial wood chipper:15-25t/h2.Crush big logs into small chip:2-5cm
3.Feed door:35*80cm
4.220+7.5*2+1.5kw
5.CE,ISO9001
We produce biomass pellet making line machines, such as wood logs debarking machine, wood logs splitter, wood sawdust making machine ,wood chipper, hammer mill, grass/straw cutter , straw bale crusher ,pellet machine and briquette machine, dryer and cooler, screener, mixer , biomass pellet boiler ,pellet packing machine and all conveyors etc..For wood chipper, we have two types , one is drum wood chipper, the other is disc wood chipper, for drum industry wood chipper machine details, as below :
1.Industry wood chipper machine is mainly used to crush big wood logs or timber
wood branches, furniture waste, long bamboo into small chips , the thickness of last chips is 1.5mm-3mm, length and width about 20-50mm, the knives gap can be adjusted ,then outlet chips dimension will be adjusted.
2.Industry wood chipper machine contains 4m length feeding belt conveyor, when conveying logs, the speed can be adjusted.Also it can connect with outlet conveyor to transport away crushed wood chips. The outlet conveyor can be installed at the chipper bottom or installed at the behind of chipper.
3.Industry wood chipper machine has knives grinder,which can grind knives never after certain time, no need to change knives often. The full unite wood chipper contains 4m length feeding conveyor ,outlet conveyor, knives grinder, electrical control cabinet etc..
4.Industry wood chipper machine has limit feeding door dimension ,for example GX2113, feed door size is 350*800mm, means raw wood logs should be smaller than35*80cm , but length no limit, feeding speed can be adjusted.
5.Industry wood chipper machine is hot selling more than 8000sets in 2012 year , greatly welcome to ask me for details, have big discount if order large quantity.
Model |
Capacity (t/h) |
Power (kw) |
Feeder size (cm) |
Chips size (mm) |
Rotate knives (pieces) |
GX216 |
5-8 |
55+3+1.5 |
23*50 |
30 |
2 |
GX218 |
8-15 |
110+5.5+1.5 |
30*68 |
30 |
2 |
GX2113 |
15-25 |
220+7.5*2+1.5 |
35*80 |
30 |
2 |
