Specifications
1.alfalfa pellet mill:0.7-1.2t/h2.make alfalfa pellet:2-8mm
3.Flat die,auto lubricate oil
4.90kw
5.CE,ISO9001
We produce biomass pellet making line machines such as wood logs splitter, wood logs debarker, wood chipper, hammer mill, straw bale cutter, grass cutter, mixer, dryer and cooler, pellet machine and briquette machine, pellet packing machine and conveyors etc. , for flat die alfalfa pellet mill details as below :
1.Flat die alfalfa pellet mill can press biomass pellet and fertilizer granules from biomass waste or fertilizer waste, raw materials such as biomass from sawdust, rice husk, agricultural stalk, straw, peanut shell, sun flower, lucerne ,paper ect fertilizer waste such as animal manure, plant waste, chemical products and so on.
2. Flat die alfalfa pellet mill can press 2-8mm diameter pellets, last density is high , there is knive installed nearby pellet mill outlet door, which can adjust last pellet length , very convenient to operate .
3. Flat die alfalfa pellet mill has one flat die inside ,its flat die hole can be changed into from 2mm-8mm , for example if install 4mm hole die , then will produce 4mm diameter pellets ,Pellet density is 1.1-1.4ton/m3.
4. Flat die alfalfa pellet mill adopts Germany high technology ,which is our national patent machine. the flat die has the unique advantages to produce larger pressure than ring die pellet mill. in this way rollers and bearings are both enlarged , which can produce larger pressure. for ring die pellet mill, its ring die is restricted by its diameter, rollers can not be enlarged enough, bearing room is smaller , so the bearing are not strong enough to withstand pressure. especially for crude fiber biomass waste, their adhesive is very low and needs high pressure to press good pellets,
5. Flat die alfalfa pellet mill has auto lubricate spare part oil system, which can lubricate three rollers, vertical shaft, bearings, gears automatically , If no auto lubricate oil system, needs to add oil each four working hours manually. Very trouble to operate .
6. From SKJ3-550 model flat die alfalfa pellet mill ,contains hydraulic pump , which can adjust pressure between rollers and flat die automatically to fit for different materials pressure ratio, no need to adjust pressure manually each time . Very easy to operate.
7.Flat die alfalfa pellet mill is hot selling more than 9000 sets per year, greatly welcome to ask me for details, we have big discount for old customers at this moment.
Model |
Capacity (kg/h) |
Power (kw) |
Specification (mm) |
Weight (t) |
Size (mm) |
SKJ2-120 |
10-30 |
3 |
4-6 |
0.05 |
1150*300*550 |
SKJ2-150 |
20-50 |
7.5 |
4-6 |
0.15 |
1260*400*650 |
SKJ2-200 |
50-100 |
11 |
4-6 |
0.2 |
1300*500*850 |
SKJ2-250 |
100-300 |
15 |
4-6 |
0.5 |
1400*600*1000 |
SKJ2-280 |
200-400 |
22 |
4-6 |
0.65 |
1760*670*1600 |
SKJ2-300 |
300-500 |
30 |
4-8 |
0.76 |
1860*670*1600 |
SKJ3-350 |
300-500 |
37 |
2-8 |
2.2 |
1900*850*1750 |
SKJ3-450 |
500-800 |
55 |
2-8 |
4.3 |
2300*1100*1900 |
SKJ3-550 |
700-1200 |
90 |
2-8 |
5.5 |
2350*1100*2050 |
SKJ3-800 |
1500-2500 |
160 |
2-8 |
6.8 |
3200*1235*2700 |
SKJ4-1200 |
3000-5000 |
320 |
2-8 |
19 |
3800*1700*4200 |
