Specifications
1.feed mixer:500kg/batch2.11kw
3.mix animal feed soybean,maize,grain powder
4.double paddle shaft
5.CE,ISO9001
We are a professional manufacturer to produce animal feed pellet making line machines ,such as feed crusher, dryer and cooler, pellet machine, various mixer, dryer and cooler, pellet crumbler, screener, pellet packing machines and various of conveyors etc. , for feed mixer, we have two types :1. Double paddle shaft mixer and single Ribbon shaft mixer , for double paddle shaft feed mixer, as below :
1.Feed mixer is widely used in mixing the animal feed and fertilizer powder, granule e.c.t .various liquid can be added. Mixing time per batch is just 30-90 seconds, Now it is widely used in animal feed industry, fertilizer industry, aquatic product breeding, chemical industry, aquatic product breeding, medicine and so on.
2. Feed mixer has full length discharging doors, generally input and bottom output doors are both two ,the output doors both have manual and pneumatic type, generally larger than 1000 Model generally will install pneumatic type, in this way, no need to operate by manual. The discharge speed is fast, and there is no residual, but pneumatic discharging type needs to buy extra air compressor.
3. Feed mixer mixing time is short (30-90seconds/batch). Adding input and output time, the mixing time is about 10-15minutes per batch(full load working), it can mix 4-6times per hour. The degree of homogeneity is high(CV is smaller than 5%)
4. Feed mixer has double paddle shafts ,mixing efficiency and working balance are both very high .all steel materials of mixer can be changed into full stainless or just carbon steel , that will be designed according to your mixing materials characteristics.
5.Feed mixer paddle shaft mixing balance degree is very stable , when works, it will no shake, also the gap between shaft and tank body is very reasonable , now this animal feed mixer is our national Free inspection products.
Feed mixer technical information
Model | SSHJ- 100 | SSHJ- 250 | SSHJ- 500 | SSHJ- 1000 | SSHJ- 2000 | SSHJ- 3000 | SSHJ- 5000 |
Output (kg/batch) | 100 | 250 | 500 | 1000 | 2000 | 3000 | 5000 |
Power(kw) | 3 | 5.5 | 11 | 22 | 30 | 37 | 45 |
Actual volume(CBM) | 0.2 | 0.5 | 1 | 2 | 4 | 6 | 10 |
Homogeneity degree (CV) | <5% | ||||||
Mixing period of the machine (s) | 40-90 | ||||||
Inner shaft | Double paddle shaft | ||||||
High quality, high service
Your satisfaction is our permanent pursuit!
Zhangqiu Yulong Machine Co., Ltd.
Contact Person: Monica Zhang
T.P: 86-0531-83483996
FAX: 86-0531-83483378
M.P: 86-18615685035
TradeManager: cn1500084279
Skype: monica29363
QQ: 755918313
