High Temperature Industrial Hydraulic Steam Rubber Hose Pipe
- FOB QINGDAO
You May Like
-
Flexible Corrugated Steam Hose Flex Pipe
-
High Pressure Steam Hose High Temp Resistant
-
Hydraulic Rubber Hose / Flexible High Pressure Steam Hose
-
Flexible High Temperature High Pressure Steam Rubber Hose
-
High Pressure Steam Rubber Hose Suppliers From China
-
2 Layer Fiber Spiral Heat-resistant (steam) Rubber Hose
Product Details
| Place of Origin | Shandong, China | Brand Name | aofenglian | |
| Model Number | 13MM-152MM |
Product Description
High temperature Industrial Hydraulic Steam Rubber Hose pipe
Fiber spiral (braid) heat-resistant (steam) rubber hose
Used to convey saturated vapour or over-heated water with the temperature not higher than 140℃.
The layer has good property of heat-resistance. The body is soft, light and convenient with a good property of bending. The burst pressure of the hose is ten times or more higher than the working pressure.
Inside Diameter(mm) |
Layer | Working Pressure MPa Kgf/cm² | Normal Length | Max Length (m) | ||
Size | Tolerance | M | Tolerance | |||
9.5 | ±0.5 | 2 | 0.6(6) | 30 | ±1% | 100 |
13 | ±0.5 | 2 | 0.6(6) | 30 | ±1% | 100 |
16 | ±0.5 | 2 | 0.6(6) | 20 | ±1% | 100 |
19 | ±0.5 | 2 | 0.6(6) | 20 | ±1% | 100 |
25 | ±0.5 | 2 | 0.6(6) | 20 | ±1% | 100 |
Heat-resistant (steam) rubber hose
Used to convey saturated vapour or over-heated water with the temperature not higher than 140℃.
The layer has good property of heat-resitance. The burst pressure of the hose is ten times or higher than the working pressure. (Pressure can be made according to the clients' demand.)
Inside Diameter(mm) | Outside Diameter(mm) |
Layer | Working Pressure MPa Kgf/cm² | Normal Length | Max Length (m) | |||
Size | Tolerance | Size | Tolerance | M |
Tolerance | |||
19 | ±0.5 | 33 | ±1.0 | 4 | 0.6(6) | 20 | ±1% | 60 |
25 | ±0.5 | 40 | ±1.0 | 4 | 0.6(6) | 20 | ±1% | 60 |
32 | ±0.5 | 48 | ±1.0 | 4 | 0.6(6) | 20 | ±1% | 60 |
38 | ±0.5 | 54 | ±1.2 | 4 | 0.6(6) | 20 | ±1% | 60 |
45 | ±0.7 | 61 | ±1.2 | 4 | 0.6(6) | 20 | ±1% | 60 |
51 | ±0.7 | 69 | ±1.4 | 4 | 0.6(6) | 20 | ±1% | 60 |
64 | ±0.8 | 81 | ±1.6 | 4 | 0.6(6) | 20 | ±1% | 40 |
76 | ±0.8 | 93 | ±1.6 | 4 | 0.6(6) | 20 | ±1% | 40 |
102 | ±0.8 | 122 | ±1.6 | 6 | 0.6(6) | 20 | ±1% | 40 |
Wire braid heat-resistant (steam) rubber hose
Used to convey saturated vapour or over-heated water with the temperature not higher than 140℃. Used as soft pipeline in the nachines such as the steamcleaning machine, steam hammer, the flat panel sulphurizing machine and plastic-filling machine ect.
Inside Diameter(mm) | Outside Diameter(mm) |
Min bend radius (mm) | Working Pressure MPa Kgf/cm² | Normal Length | Max Length (m) | |||
Size | Tolerance | Size | Tolerance | M |
Tolerance | |||
13 | ±0.5 | 25 | ±1.0 | 130 | 1.8(18) | 20 | ±1% | 100 |
16 | ±0.5 | 30 | ±1.0 | 160 | 1.8(18) | 20 | ±1% | 50 |
19 | ±0.5 | 33 | ±1.0 | 190 | 1.8(18) | 20 | ±1% | 50 |
25 | ±0.5 | 40 | ±1.0 | 250 | 1.8(18) | 20 | ±1% | 50 |
32 | ±0.5 | 48 | ±1.0 | 320 | 1.8(18) | 20 | ±1% | 40 |
38 | ±0.5 | 54 | ±1.2 | 380 | 1.8(18) | 20 | ±1% | 40 |
It packed with woven bag or as cutomers' request.
Penglai Linge Rubber & Plastic Co.,Ltd and Penglai Aofenglian Rubber & Plastic Co.,Ltd was established in 1989, is a professional company mainly for the research, development, design and manufacture of all kinds of rubber hose. The area of company is about one hundred and eight mu. The registered trade mark of the products are "DENGFENG", "LINGE", "YUANHONG", "JIAGONG", "AOFENGLIAN"
Our company own advanced production equipment,well-equipped testing,strong innovation and research,strong technical force.All of the products were insured by the Insure Company of Chinese People.
Why choose us:
1. We consistent good quality with reasonable price.
2. Stable production capacity.
3. Delivery in time.
4. Good quality control.
1.Your inquiry related to our product will be replied within 24hours.(E-mail or TM)
2.Well-trained & experienced staff are to answer all your inquiries in English.
3.Your business relationship with us will be confidential to any third party.
4.Good after-sale service offered, please get back if you got question.
5.Welcome to our company.
Our company mainly produces all types of Metal-welding and cutting rubber hose, air pressure rubber hose, water delivery and suction rubber hose, oil delivery and suction rubber hose, heat-resistant (steam) and suction rubber hose, acid (alkali) delivery and suction rubber hose, wear-resistant rubber hose, wire braid (spiral) hydraulic rubber hose, dredging harbor project rubber hose, special purpose rubber hose.
