1.flat die feed pellet machine production line fit for home use or factory to do trail experiment. it can press 2to8mm diameter biomass fuel pellet, animal feed and fertilizer pellets , raw biomass materials can be biomass waste from sawdust, rice husk, agricultural stalk, straw, peanut shell, sun flower, paper ect ,animal feed materials can be grain, soybean, maize ect, fertilizer materials can be animal manure , chemical and so on .
2. flat die feed pellet machine production line can press high density pellets , for biomass , pellet density can reach 1.1to1.4ton/m3, pellet diameter can be 28mm , the knive installed nearby pellet machine outlet door can adjust the pellet length.
3.flat die feed pellet machine production line adopts Germany high technology ,which is our national patent machine.it has the unique advantages to enlarge inside flat die diameter, so roller assemble and bearings are both enlarged too, which can produce higher pressure than ring die pellet machine.ring die pellet machine inside ring die is restricted by diameter, its roller can not be enlarged enough, so the assemble bearings are not strong enough to bear larger pressure.
4. flat die feed pellet machine production line is especially fit for crude fiber biomass materials, especially for cattle or sheep feed materials straw, alfafa,rice husk ,corn stalk ,plam fiber etc its adhesive is very low, needs high pressure to press high density pellets, for biomass, the flat die animal feed pellet machine is more fit .
5. When small flat die feed pellet machine production line works, it is flat die move rotates and then take rollers work, but the whole roller assemble keeps stable . in this way will keep all materials piles up in the center of flat die , increase capacity and pelletizing efficiency .
6. flat die feed pellet machine production line can make biomass pellets for burning and make animal feed pellets to feed animal, fertilizer pellets for farm use. the engine can be installed by both electric motor or diesel engine or work connect with PTO tractor .very easy to operate .
5.flat die feed pellet machine production line is very hot selling more than 5000 sets per year , greatly welcome all friends to ask me for details. We have big discount at this moment .
Model |
Output (kg/h) |
Power (kw) |
SKJ2-120 |
30-50 |
3 |
SKJ2-150 |
50-80 |
7.5 |
SKJ2-200 |
150-250 |
11 |
SKJ2-250 |
200-250 |
15 |
SKJ2-280 |
350-500 |
22 |
SKJ2-300A |
500-700 |
30 |
SKJ2-350 |
700-800 |
30 |
SKJ2-450 |
800-1200 |
45 |
SKJ3-350A |
1000-1500 |
37 |
Amy
ZHANGQIU YULONG MACHINE CO.,LTD
Add:Nanguan Industrial Park,Xiuhui Town,Zhangqiu City ,Shandong Province
Skype:amyjiang882
QQ: 28228 34422
M.P: 86-18615685036
Tel:86-531-83483997
