Fabric Reinforced Cord Sand Blast Hydraulic Rubber Hose
Specifications
2.the layer has good property of anti-aging and anti-resistance
3.ISO9001
4. fabric cover
Cord sand blast rubber hose
Used in wind-pressured sand-spraying machine to get rid of the rust by spraying sand or with iron ball
The inside layer is wear-resisting and the outside layer good at anti-aging and wear-resistance.The burst pressure of the hose is four times or more higher than the working pressure.
Inside Diameter(mm) |
Outside Diameter(mm) |
Layer |
Working Pressure MPa Kgf/cm² |
Normal Length |
Max Length (m) |
|||
Size |
Tolerance |
Size |
Tolerance |
M |
Tolerance |
|||
19 |
±0.4 |
34 |
±0.8 |
2 |
1.0(10) |
20 |
±1% |
60 |
22 |
±0.4 |
36 |
±0.8 |
2 |
1.0(10) |
20 |
±1% |
60 |
25 |
±0.6 |
39 |
±1.2 |
2 |
1.0(10) |
20 |
±1% |
60 |
32 |
±0.6 |
50 |
±1.2 |
4 |
1.0(10) |
20 |
±1% |
60 |
38 |
±0.8 |
56 |
±1.5 |
4 |
1.0(10) |
20 |
±1% |
60 |
51 |
±0.8 |
70 |
±1.5 |
4 |
1.0(10) |
20 |
±1% |
60 |
64 |
±1.0 |
82 |
±1.5 |
4 |
0.63(6.3) |
20 |
±1% |
40 |
76 |
±1.0 |
95 |
±1.5 |
4 |
0.63(6.3) |
20 |
±1% |
40 |
Wire braided sand Blast rubber hose
Used in wind-pressured sand-spraying machine to get rid of the rust by spraying sand or with iron ball.
The inner layer is wear-resistance and the outer layer is good at anti-aging and wear-resistance. The hoe can asure high pressure and it will be not deformation . The burst pressure of the hose is four times or higher higher than the working pressure.
Inside Diameter(mm) |
Outside Diameter(mm) |
Working Pressure MPa Kgf/cm² |
Normal Length |
Max Length (m) |
|||
Size |
Tolerance |
Size |
Tolerance |
M |
Tolerance |
||
25 |
±0.6 |
39 |
±0.8 |
6.9(69) |
20 |
±1% |
40 |
32 |
±0.6 |
50 |
±0.8 |
4.3(43) |
20 |
±1% |
40 |
38 |
±0.8 |
56 |
±1.2 |
3.5(35) |
20 |
±1% |
40 |
51 |
±0.8 |
70 |
±1.2 |
2.6(26) |
20 |
±1% |
40 |
64 |
±1.0 |
82 |
±1.5 |
2.5 (25) |
20 |
±1% |
40 |
76 |
±1.0 |
95 |
±1.5 |
2.5 (25) |
20 |
±1% |
40 |
It packed with woven bag or as your request.
Penglai Linge Rubber & Plastic Co.,Ltd and Penglai Aofenglian Rubber & Plastic Co.,Ltd was established in 1989, is a professional company mainly for the research, development, design and manufacture of all kinds of rubber hose. The area of company is about one hundred and eight mu. The registered trade mark of the products are "DENGFENG", "LINGE", "YUANHONG", "JIAGONG", "AOFENGLIAN"
Our company own advanced production equipment,well-equipped testing,strong innovation and research,strong technical force.All of the products were insured by the Insure Company of Chinese People.
1.Your inquiry related to our product will be replied within 24hours.(E-mail or TM)
2.Well-trained & experienced staff are to answer all your inquiries in English.
3.Your business relationship with us will be confidential to any third party.
4.Good after-sale service offered, please get back if you got question.
5.Welcome to our company.
Our company mainly produces all types of Metal-welding and cutting rubber hose, air pressure rubber hose, water delivery and suction rubber hose, oil delivery and suction rubber hose, heat-resistant (steam) and suction rubber hose, acid (alkali) delivery and suction rubber hose, wear-resistant rubber hose, wire braid (spiral) hydraulic rubber hose, dredging harbor project rubber hose, special purpose rubber hose.
