61. Main function
Wireless Communication(3G,GPRS,CDMA,WIFI,Bluetooth),Positioning(Beidou navigation ,GPS),IC card reading(contact and contactless IC card),Epayment,Barcode(1D,2D),Camera,Thermal printer.
2. Features
l High reliability and security: high and low temperature resistant, dampproof, impact resistant (drop test), salt-fog proof.
After-sale services
Offering 24-hour Online Service
We offer 24-hour online service, and door-to-door installation service. Our hardware carry one-year warranty and software have lifetime maintenance service. Inquire today to begin sourcing. and other RFID systems. We are among the first batch of national "MOHURD Interconnection-certified" companies. As one of the members on developing magnetic IC card reader system throughout China, after 16 years of continuous development and innovation, we have already become one of the most influential enterprises in POS terminal field in Asia.
l Support vehicle license plate recognition ;
l Support wireless communication, real time time-revision, blacklist download, data collection
l Support union pay card, PBOC3.0union pay card compatible.
l Query consumption details, query according to card No., time, operator No. etc.
l Query consumption statistics, query according to card No., time, operator No. etc.
3.Technical parameters
Name: |
Portable POS( Fifth generation) |
|||
Model: |
CL-B0511B |
|||
Software Platform: | ||||
Operating system: |
Linux2.6.38 |
|||
Compiler: |
GCC-4.5.1 |
|||
QT |
QT Extended4.4.3 |
|||
Hardware specifications: | ||||
CPU: |
ARM1176JZF-S |
|||
Frequency: |
St:533MHZ,Max:800MHZ |
|||
Memory: |
DDR2:256Mbyte |
|||
HD: |
256MByte |
|||
TF-card: |
Micro TF card,Max 32GB |
|||
USB: |
Micro AB / support USB OTG |
|||
RTC: |
Support |
|||
Graphic acceleration: |
Hardware 2D,3Dgraphic acceleration |
|||
LCD: |
3.5inch TFT-LCD320*240(RGB) |
|||
TP: |
4-wire resistance-type |
|||
Loudspeaker: |
8OHM/1W buzzer |
|||
Camera: |
3Megapixel |
|||
Phone Jack: |
international standard 4 pin,support voice and earphone |
|||
Key: |
USB key, hardware logic keys |
|||
Supporting card | ||||
Read card |
Contact |
ISO 7816-3compatible (reserved);one SIM card,4 PSAM card |
||
Contactless |
ISO/IEC14443 A/B layer compatible |
|||
voice function(reserved) | ||||
voice |
input |
Only through ear phone |
||
output |
GSM,only support ear phone |
|||
scanning:scanning and camera only choose one | ||||
scanning: |
1D, 2D barcode scanning |
|||
camera:scanning and camera only choose one | ||||
camera: |
Support 3Megapixel |
|||
Positioning | ||||
Positioning: |
Beidou 2 |
Optional |
||
GPS | ||||
Wireless communication | ||||
Bluetooth |
BT 2.1 |
default |
||
Bluetooth 4.0 BLE |
optional |
|||
WIFI |
IEC802.11 B/G/N |
default |
||
IEC802.11 A/B/G/N |
optional |
|||
GPRS |
Data,SMS,Voice |
default |
||
CDMA |
Data,SMS,Voice |
optional |
||
3G |
Data,SMS,Voice |
optional |
||
Power supply | ||||
Working voltage: |
DC:9V 2A/3A |
|||
Battery supply: |
Removable ,7.4v@3800mA/polymer lithium battery ;Wide temperature battery |
|||
Power consumption: | ||||
Power consumption:: |
48H(Standard environment and configuration / theoretical value) Power off:8uW |
|||
Working environment | ||||
Working temperature:: |
-25℃~65℃ |
|||
Storage temperature: |
-40℃~75℃ |
|||
Working Humidity: |
0-90%(non-condensing) |
|||
|
physical parameter
| ||||
Dimension: |
218.2*87.8*61.6mm |
|||
Housing material: |
engineering plastics,TPU |
|||
LCD display | ||||
display: |
3.5" TFT LCD 320*240 (RGB) |
|||
Pilot lamp: |
LED Pilot lamp |
|||
Key function | ||||
Key: |
23-key keyboard |
|||
Sound prompt | ||||
sound: |
buzzer,loudspeaker |
|||
RFID | ||||
standard: |
ISO-14443 Type A/B |
|||
Reading distance: |
0~50mm |
|||
Working frequency: |
13.56Mhz |
|||
Card capacity: |
91880000 |
|||
Card type: |
Mifare 1 card,CPU, Union pay IC card |
|||
Interface | ||||
Communication interface: |
USB |
|||
Printing function | ||||
printing module: |
Built-in thermal printer |
|||
Receipt width: |
58mm |
|||
Working pattern | ||||
Working pattern: |
Stand alone or network |
|||
Alarm | ||||
Alarm |
Insufficient balance or data is full |
|||
Data collection | ||||
Wireless data collection |
WIFI,Bluetooth,GPRS,CDMA,3G |
|||
Cable data collection |
USB cable data collection |
|||
4. Customers
