WE67K- 400 / 6000 Electric Hydraulic Servo CNC Synchronous Press Breaks

WE67K- 400 / 6000 Electric Hydraulic Servo CNC Synchronous Press Breaks thumbnail-1
WE67K- 400 / 6000 Electric Hydraulic Servo CNC Synchronous Press Breaks photo-1
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
EMM
Model Number:
WE67K- 400 / 6000
Contact Supplier Request Quote Chat Now
Extreme Machinery Manufacture Co., Ltd. (Jingjiang)
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name EMM
Model Number WE67K- 400 / 6000
Machine Type Press Brake
Raw Material Steel Bar
Material / Metal Processed Stainless Steel
Power Cnc
Automation Manual

Specifications

Light encodes of two sides checking feedback of synchronous position
The back gauge equipped with screw mandrel and linear

Main Elements

1.  DA-65W  CNC System-------DELEM, Holland

2.  Hydraulic System----BOSCHor Rexroth

3.  Light encodes of two sides checking feedback of synchronous position

4.  The back gauge equipped with screw mandrel and linear slider is driven by the high-powered servo motor.

5.  Hydraulic defection compensation is operated by DNC system.

6.  A set of standard of upper and lower moulds.

7.  Front Supportframe.





Major Parameters



Serial Number

Item

Unit

Value

1

Nominal pressure

KN

4000

2

max bending length

mm

6000

3

Uprights distance

mm

4710

4

Ram travel

mm

250

5

Backgauge travel

mm

800

6

max opening height

mm

400

7

throat depth

mm

       1000

8

worktable width

mm

300

9

ram speed

unloaded

mm/s

90

working

mm/s

15

return

mm/s

70

10

major motor

Kw

30

11

dimension

mm

6100×2410×3750
