Description
Micro-Perf/Folding & Creasing machine
The Micro-Perf/Cut & Crease machine is the answer to your problems as it brings together creasing, micro-perforating and cutting in a single multi-functional device.
Versatile male blade holder that accommodates any perf/cut/crease applications as little as 5mm apart
Eliminates outsourcing of creasing and micro-perforating
Features of the Micro-Perf/Cut & Crease Combo...
Technical parameters
• Creasing speed: up to 2000 sheets/hour
• Maximum paper size: 25.1" (640 mm)
• Minimum paper size: 2" (50mm)
• Paper weight: 45 - 450 gsm
• Paper load capacity: 50 sheets (20 lbs paper)
• 4 pre-set creasing patterns:
• With electronic controls and fine adjustments, easy to operate
• manual paper feed
• Electrical: 110/220VAC, 50Hz
• Package dimension: 43.3*34.6*47'
• Package weight: 570 lbs
Accessories
Perforating blade 1 sets
Creasing tool hinge 4 sets
cutter tool 1 sets
Tri-Creaser Fast Fit Benefits
Completely eliminates fibre cracking 100%on stock ranges 85-350gsm
Produces a crease that is as good or better than a flatbed Cylinder impression
Produces any one of a choice of multiple crease settings for any imaginable print/stock combination, and works like magic on difficult toner based digital output
Works just as well when it creases and folds against the grainas it does with it
Works as fast as your folding machine can run with no limitations on speed
Split creasing ribs means it takes only minutes to set up and seconds to change from one crease setting to another
No more removing shafts to change crease settings
Pays for itselfwithin 1-4 job runs
Saves expensive outsourcing costs plus hours and hours of time
Gets the work to your customerfaster
Single
2 BookS spine creasing mould 2 set/sets
Ctraddle cut
Dotted line
Creasing mould 2 set/sets
Cutting mould 1set/sets
