EB100 3D tube bending machine for sales
Main Features
1. PLC control unit, Pro-face touch screen, and conversational input.
2. Encoder controls turning and bending angles, the bending angle set in 0-190 degree.
3. Pipe is fed at any angle by hand. The angle can be divided into 8 times for feeding.
4. Mobile foot switch with three functions: automatic start, emergency stop and resuming, the safety is very high.
5. Hydraulic drive, large-volume cooling circulation system to make the copper tube bending machine runs more steadily and extends its use life.
6. Mould (die) exchanging is simple and convenient.
7. The delicate design of copper tube bending machine makes the pipe bending precision high and bending space large
8. Recommended industries: Automobile fitting (brake lever, bumper, silencer, seats and others), motorcycle, bicycle, air conditioner, body-building equipment, steel-made furniture, sanitation etc.
Technical parameters of EB100 3D tube bending machine for sales
Model |
EB100 |
Remark |
|
Max bending capability |
100mm×8mm |
1. The Minimum bending diameter based on the pipe diameter 2.The Max bending diameter can according to the customer’s requirement 3.The Max length of mandrel can according to customer’ requirement |
|
Max bending radius |
R350mm |
||
|
Min bending radius
|
According to pipe diameter |
||
Max bending angle |
190° |
||
Max feeding length |
3000mm |
||
Working speed |
Bending speed |
Max 30°/s |
|
Rotary speed |
Max 160°/s |
||
Feeding speed |
Max 800mm/s |
||
Working accuracy |
Bending accuracy |
±0.1° |
|
Rotary accuracy |
±0.1° |
||
Feeding accuracy |
Mechanical valuing |
||
Bending method |
Hydraulic bending |
||
Power of rotary servo motor |
2kw |
||
Max bending unit |
16 units |
||
Max storing unit |
16 groups |
||
Motor power |
15kw |
||
Oil pressure |
14 Mpa |
||
Size |
5700 x 1350 x 1400mm |
||
Weight |
6000kg |
||
standard export package Of EB100 3D tube bending machine for sales
Presale Service
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
Service during the Sale
1. We are manned with professional salesmen and technicians to provide the information, technical support and the optimal solutions with high cost performance.
2. Based on the specific requirements of customers and the lead time, we will formulate a rigorous operation process. Through the close cooperation of Commodity Department, Sales Department, Technical Department and the Ocean Shipping Department, we are devoted to timely supplying customers with superior machines.
3. Generally, certain quantity of quick-wear parts will be delivered with the goods. The delivery deadline depends on the specific order, which is usually within 1 to 3 months.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
EMM is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team members includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
What kind of payment terms will be acceptable by our company?
RE:30% deposit by T/T in advance , the balance paid by T/T after commodity inspection and before shipment of the copper tube bending machine .
