Product Details
Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | EMM |
Model Number: | EM502A-1S | Machine Type: | Pipe and Tube Bending Machine | Raw Material: | Pipe |
Material / Metal Processed: | Carbon Steel | Power: | Hydraulic | Automation: | Automatic |
Extra Services: | Other, bending | Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
EM502A-1S 3d hydraulic tube bender machine
EM502A-1S 3d hydraulic tube bender machineseeks excellence on the control aspect. Its characteristics are as following:
1. Electric control system: adopts famous controller in Japan,for example, the servo driver, servo motor, location mold group, CPU and so on from Mitsubishi Clubs or Yasukawa, which is of high capability and excellent steadiness.
2. Extra-large CPU of Mitsubishi can store 400 groups of file editions. When the storage space is inadequate, transform software can be installed in the computer and then the files can be stored in hardware so as to expand edition groups indefinitely.
3. WINDOWS operating system is installed in the industrial computer to match with Mitsubishi servo system; therefore, apart from the advantage of Mitsubishi servo drive, it owns the convenience of file management of WINDOWS operating system. lt can also store the files in hardware or disk to indefinitely expand edition groups.
4. Function of automatically detecting error and fault, which is displayed on the screen for operators to cancel the fault easily.
5. All the process documents are inputted by touch control screen.
Specification/Model | Unit | EM183A-1S | 1.EM252A-1S 2.EM253A-1S | 1.EM382A-1S EM383A-1S | 1.EM632A-1S 2.EM633A-1S | |
Max bending capability | mm | Φ18*1.6 | Φ25*1.6 | Φ38*2 | Φ63*4 | |
Max bending radius | mm | R80 | R100 | R180 | R250 | |
Min bending radius | mm | According to pipe OD | According to pipe OD | According to pipe OD | According to pipe OD | |
Max bending angle | degree | 195 | 190 | 190 | 190 | |
Max feeding length | mm | 1500 | 2000 | 2500 | 3000 | |
feeding method | direct feeding/clamping feeding | |||||
Working speed | Bending speed | Max 200°/s | Max 200°/s | Max 150°/s | Max 85°/s | |
Rotary speed | Max 200°/s | Max 200°/s | Max 200°/s | Max 200°/s | ||
Feeding speed | Max 1000mm/s | Max 1000mm/s | Max 1000mm/s | Max 1000mm/s | ||
Working Accuracy | Bending accuracy | ±0.1° | ±0.1° | ±0.1° | ±0.1° | |
Rotary accuracy | ±0.1° | ±0.1° | ±0.1° | ±0.1° | ||
Feeding accuracy | ±0.1mm | ±0.1mm | ±0.1mm | ±0.1mm | ||
Information inputting method | 1.Axis(X,Y,Z) | 1.Axis(X,Y,Z) | 1.Axis(X,Y,Z) | 1.Axis(X,Y,Z) | ||
ing value(Y,B,C) | ing value(Y,B,C) | ing value(Y,B,C) | ing value(Y,B,C) | |||
Bending method | 1.Servo bending: 1KW(more than 3 axis) | 1.Servo bending: 2KW(more than 3 axis) | 1.Servo bending: 5KW(more than 3 axis) | 1.Servo bending: 7KW(more than 3 axis) 2.Hydraulic bending | ||
2.Hydraulic bending | 2.Hydraulic bending | |||||
Power of rotary servo motor | KW | 0.4 | 0.4 | 0.75 | 0.75 | |
Power of feeding servo motor | KW | 0.75 | 0.75 | 1 | 1.5 | |
Max bending unit | 16 units (PLC) | |||||
Max storing components | 2000000 groups (PLC) | |||||
Motor power | kw | 3 | 3 | 4 | 5.5 | |
Max Oil pressure | mpa | 10 | 12 | 12 | 12 | |
Size | mm | 2760*690*1000 | 3000*780*1100 | 3860*720*1230 | 5200*1300*1560 | |
Weight | kg | 800 | 1000 | 1500 | 3000 |
EM502A-1S 3d hydraulic tube bender machine
Presale Service
We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the
warranty, we only charge for the basic costs of parts.
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
EMM’s is a comprehensive enterprise dealing economic and technology cooperation that specializes in manufacturing for metal fabrications and distributing of all types of machinery tools Including Industrial Equipment, fabricating equipment, sheet metal equipment and production line machinery.
We are not only trading with customers from domestic and oversea but also providing customers with technical, commutation and after sales support.
Our dedication to the highest quality products and services have establish excellent trade relations with customers from all over the world. EMM’s team memebers includes qualified sales specialists and highly trained technical professional to help provide quick service and the best quality of work in order to meet our customer needs.
EM502A-1S 3d hydraulic tube bender machine
1. 100% by T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3. 100% by L/C at sight;
4. 100% by 30, 60 or 90 days usance credit.
EM502A-1S 3d hydraulic tube bender machine
