L1324A Semi-automatic Turning Lathe /lathe Machine for Cutting Metal

Extreme Machinery Manufacture Co., Ltd. (Jingjiang)

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Semi-Automatic

Max. Swing Diameter 350mm

Place of Origin Jiangsu, China

Brand Name EMM

Model Number L1324A

Voltage 380v/220v/415v

Power(W) 750

Dimension(L*W*H) 2360x1000x1200

Weight 1760kg

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1. long life
2.low noise.
3.high rigidity and precision

L1324A semi-automatic turning lathe /lathe machine for cutting metal

Feature

1-Hardened and grinded bed way and gears in headstock are with long life and low noise.

2-Spindle system is of high rigidity and precision.

3-The machine have powerful headstock gear train, high rotating accuracy and smooth running with low noise.

4-An overload safety device is provided on the apron.

5-Has a pedal or an electromagnetic braking device.

Main specification

Model Item			L1324A
Max. swing diameter	Over bed	mm	Ø350
Max. swing diameter	Over carriage	mm	Ø185
Max. length of workpiece		mm	1000
Spindle	Spindle bore	mm	Ø40orØ52
	Taper of bore		M.T.No.5 or M.T.No.6
	Number of speeds		12
	Range of speeds	r.p.m	40-1800
Thread cutting	Metric Range/No.		0.5~20mm/24
	Whitworth Range/No.		72~1-5/8t.p.i/61
	D.P. Range/No.		96~3-1/4D.p/45
	Module Range/No.		0.25~10M.P/20
Range of feeds	Longitudinal	mm	0.04-2.46(0.0015"-0.0913")
Range of feeds	Cross	mm	0.03-1.23(0.0006"-0.0365")
Tailstock sleeve	External diameter	mm	Ø60
	Taper of bore	mm	M.T.No.4
	Max. traverse	mm	120
Max. travel of compound rest		mm	100
Max. cross slide travel		mm	210
Max. size of tool shank(W×H)		mm	20×20
Power of main motor(double speeds)		kw	3/4
Overall dimensions(L×W×H)		mm	2360×1000×1200
Net weight		kg	1760
