Specifications
Q35-16 mechanical ironworker1.easy maintenance
2.light weight
3.gain time
4.improve work efficiency
Q35-16 mechanical ironworker
The mechanical ironworker machine is an ideal equipment for shearing square bar,
angle, round bar, C channel, I beam, punching and notching.
shell feed plate plus raincloth
FOB shanghai by sea
About us
Extreme Machinery Manufacture (EMM) has improved the metal processing proficiencies of industry professionals since 2008. We are a Chinese manufacturer that specializes in the design, production, distribution, and servicing of metal processing equipment. In addition to various types of lathes and CNC centers, we also offer ironworkers, press brakes, plate shearing machines, and PU foam machines. Designed for highefficiency industrial applications, our automated solutions are optimized for sheet metal production lines of all types. Our facilities are fully equipped to handle OEM requests. Client-side blueprints are accepted as a part of our customization program.
Our company is headquartered in Jingjiang city, within the folds of the Yangtze River Delta. This prime geographic location is in close proximity with the international airports and harbors of major cities including Shanghai and Nanjing. A complete industrial supply chain allows us to offer highly competitive prices to customers in regions including the Middle East, Southeast Asia, South America, and Europe. We also have export destinations in countries such as America, Russia, Ukraine, India, Indonesia, Mexico, Brazil, UAE, Malaysia, Australia, South Africa, Chile, South Korea, and Egypt.
Both our technical taskforce and management team consist of industry professionals. Their expertise allows us to fully satisfy the requirements of each customer. We wish to achieve progression through sincere business conduct and mutually beneficial arrangements. As a people-oriented company, EMM advocates virtues such as honesty, proficiency, and perseverance. In the continuous pursuit of excellence, we are constantly seeking opportunities to optimize and innovate.
Thank you for your interest in our products and services. We look forward to hearing from you soon!
After-Sale Service
1. One year warranty is provided.
2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the warranty, we only charge for the basic costs of parts
3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.
Payments terms:
1.T/T;
2. 30% deposit by T/T, the balance paid by L/C at sight;
3.100% by L/C at sight;
Delivery Detail
20-30 workdays /ironwork manufacturers
Q35-16 mechanical ironworker
mechanical ironworker | mechanical ironworker | mechanical ironworker | mechanical ironworker | mechanical ironworker | mechanical ironworker | mechanical ironworker | mechanical ironworker mechanical ironworker || mechanical ironworker mechanical ironworker
Model |
Q35-16 |
Punching pressure(ton) |
63 |
Max. Shearing thickness of steel plates(mm) |
16 |
Tensile strength of sheet metal(N/mm²) |
≤450 |
Angle of shearing |
13° |
Shearing sizes of one stroke(WXH)(mm) |
20x140 |
Ram stroke(mm) |
26 |
Number of stroke(times/min) |
36 |
Depth of throat(mm) |
450 |
Punching thickness(mm) |
16 |
Max. diameter of punching(mm) |
28 |
Main motor power (KW) |
4 |
Overall dimensions(L x Wx H) (mm) |
1877x1945x725 |
Net. Weight(kg) |
2830 |
Q35-16 mechanical ironworker
