All for Ironworker Q35Y-35
US$ 21,300 - 31,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal, not
Power Source:
Hydraulic
Payment & Shipping
Payment Methods:
Port of Shipment:
Shnghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
All for Ironworker (Q35Y-30)US$ 19,200 - 24,400MOQ: 1 Set -
Q35Y-20 Hydraulic IronworkerUS$ 5,000 - 10,000MOQ: 1 Unit
-
Mechanical Shearing Cutting Machine Q35Y-13(IW45)US$ 6,000 - 7,200MOQ: 1 Unit
-
Q35Y-30 Steel Coil Cutting MachineUS$ 7,300 - 15,000MOQ: 1 Set
-
Multi-function Small Hydraulic Punching Q35Y-20(90 Ton)US$ 8,500 - 10,500MOQ: 1 Unit
Condition
New
Power Source
Hydraulic
Place of Origin
Jiangsu, China
Brand Name
EMM
Model Number
Q35Y-35
Voltage
480 V
Power(W)
13000 W
Weight
7600 KG
Dimension(L*W*H)
2610*1250*2340 mm
Certification
ISO9001
Warranty
1 YEAR
Specifications
1.all for ironworker2.hydraulic machine
3.iron machine
4.punching machine
5.stamping machine
All for ironworker Q35Y-35
STANDARD
*Full stroke adjustment.
*Low power inching and adjustable stroke.
*Universal die bolster punching up to 57mm as standard.
*Large punch table with multi-purpose bolster removable table block for overhang channel/joist flange punching.
*Machines with very low maintenance requirements.
*Punch adaptors
*Swing away punch stripper unit
*Easy change punch holder
*Universal die bolster
Technical Capacities and Specifications
Model |
Unit |
Q35Y-35 |
Punching Pressure Ton |
Ton |
165 |
Max. capacity |
mm |
40x32 |
Diameter x thickness |
mm |
57x18 |
Stroke length |
mm |
80 |
Standard throat depth punch |
mm |
165 |
Largest hole(standard equipment) |
mm |
57 |
Largest hole(optional equipment) |
mm |
255 |
Maximum section |
mm |
380 |
Working height |
mm |
1156 |
