UT436B Vertical and Horizontal Turret Milling Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
EMM
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
US232 Benchtop Cnc Milling MachineUS$ 8,000 - 9,000MOQ: 1 Set -
EM5S/5V Vertical Turret Milling Machine ManufacturerNegotiableMOQ: 1 Set
-
EMMCHINA Milling Machine for MetalUS$ 5,698 - 10,898MOQ: 1 Set
-
DM7020 Drilling&milling MachineUS$ 5,000 - 30,000MOQ: 1 Set
-
EMM DM7020 Drilling and Milling MachineUS$ 5,000 - 30,000MOQ: 1 Set
Condition
New
Place of Origin
Jiangsu, China
Brand Name
EMM
Model Number
UT436B
Type
Horizontal
CNC or Not
Normal
Voltage
380V
Power(W)
4kw
Dimension(L*W*H)
2000*2000*2250mm
Weight
3000kg
Certification
CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
UT436B Vertical and Horizontal Turret Milling MachineUT436B Vertical and Horizontal Turret Milling Machine
Features:
- Taiwan high speed milling head, 5HP, and work table can turn 45 degrees processing of a wide range of, Three-axis automatic feed, large torque and strong power, 2HP Fast-moving 2000mm/min.
- The fuselage and the lifting platform for the square guide.
Specification:
Specifications |
UT436B |
Spindle taper |
ISO40 (Vertical) ISO50 (Horizontal) |
Arm travel |
500 |
Spindle speed range(r.p.m) |
70-7200 (Vertical) |
Table size |
1630*360 |
Table travel |
1000*350*420 |
Main motor(kw) |
4.0 (Horizontal) |
Distance from vertical spindle to table surface(mm) |
135-485 |
Distance from horizontal spindle to table surface(mm) |
0-350 |
Overall dimensions(mm) |
2000×2000×2250 |
N.W/G.W (kg) |
2850/3000 |
