Specifications
prefabricated modren house1.ISO,TUV,SGS certification
2.Insolation&Anti-quake
3.Easily assemble & move
4.Low cost
Foldable cheapest price prefabricated low energy modren house prices
Description of prefabricated modern price
The prefabricated modern price , that's good to sleep ,which is sealed tight, thermal insulation, waterproof , fireproof, moisture proof, and beautiful in appearance. Its external wall and partition wall use color-coated steel sandwich panel has a good appearance effects, and long service life, easy installation, transportation convenience, disassembly recycling. Enjoy the safety and environmental friendly advantages of prefabricated modern price from KEHOUSE.
Steel is Stronger . Safer . Smarter!
| Advantage of prefabricated modern price | ||
| No. | Item | Content |
| 1 | Firm structure | Safe & reliable light steel flexible structure with EPS sandwich panel |
| 2 | Widely application | Construction site, office building, family living house,dormitory, canteen, recreation room, washing room, outdoor temporary building, |
| 3 | Flexible layout | customized design and optimized material application |
| 4 | Long life | Anti-rust and normally more than 20 -25 years using life. |
| 5 | Easy assembly | 6 worker can finish 300sqm prefab house in 2 days |
| 6 | Recycling use | Reused for more than 5 times |
Technical Parameters of prefabricated modern price
A,Overall weight:50~60kg/sqm
B,Seismic fortification intensity:8 grade
C,Wind-proof capacity:wind speed 20m/s, resist 8grade wind
D,Floor loading capacity:150kg/sqm E,Roof loading capacity:60kg/sqm
F,External wall bearing capacity:50kg/sqm
The main materials of prefabricated modern price | ||||
No. |
Component |
Specification |
Material thickness |
Remark |
I. Main steel structure | ||||
1 |
Ground beam |
8#C steel |
1.8mm |
Blue paint |
2 |
Ring beam |
8#C steel |
1.8mm |
Blue paint |
3 |
Column |
Double 8#Csteel |
1.8mm |
Blue paint |
4 |
Straight girder |
8#C steel+50×30 square tube |
1.6mm+1.2mm |
Iron red |
5 |
Floor purlin |
8#C steel |
1.6mm |
Iron red |
3 |
A shape beam |
80#C steel + 50x30 flat pipe |
1.8mm+1.2mm |
Iron red |
4 |
Roof purlin |
50×30 flat pipe |
1.2mm |
Slivery white |
5 |
Stair |
16#C steel |
2.5mm |
Black paint |
stair tread |
steel plate |
2.5mm |
Black paint |
|
walkway board |
steel plate |
2.5mm |
Black paint |
|
6 |
Canopy frame |
8#C steel |
1.8mm |
Blue paint |
7 |
Canopy frame support |
Φ25round pipe |
2.0mm |
Blue paint |
8 |
Lateral bracing |
angle steel |
3.0mm |
Blue paint |
II. Wall | ||||
1 |
External wall panel |
EPS sandwich panel or rock wood panel |
50mm,75mm,100mm for your options |
Grey white |
2 |
Inner partition board |
EPS sandwich panel or rock wood panel |
50mm,75mm,100mm for your options |
Grey white |
III. Roofing | ||||
1 |
Roof tile |
830 PU tile |
20mm |
Blue, red |
IV. Door & window | ||||
1 |
Door |
color steel sandwich panel door |
870X2100mm |
Grey white |
2 |
Window |
PVC sliding window |
Width1748×height 925mm |
|
V. Floor | ||||
1 |
Floor board |
Plywood |
15mm |
|
Application and inside looking
Construction site . Office building . Family living house . Dormitory . School . Canteen . Recreation room . Washing room . Bathroom . Outdoor temporary building etc.
Other accessories
KEHOUSE aim to provide you more than a house! If any need of below items, just let us know, we can do it for you in low price.
Simple installation step
Normally 4 workers for one installation team, only need simple tools for the installation. One team can finish 100sqm house in 4 days.
Container loading
KEHOUSE have our professional container loading workers. They will load all the components in good condition. To avoid any unnecessary damage during the long time transportation.Customers' satisfaction is our greatest wish. Trust us, your best supplier of prefabricated modern price .
Products Process of KEHOUSE
Over view of KEHOUSE
Certificate of KEHOUSE
