Movable 20 ft EPS Sandwich Panel Prefabricated Container Office

Performance

Roof load

0.5KN/sqm(can reinforce the structure as required)

Wind speed

designing wind speed: 210km/h (Chinese standard)

Seismic resistance

magnitudes 8

Temperature

suitable temperature.-50°C~+50°C

Standard Size

Length

6058mm

Width

2438mm

Height

2591mm

Clear height in door

5800x2200x2300mm

                                  Foshan Kehouse Light Steel House CO.,LTD.

Main material and specification of 20ft container

1

Size: 6058mm x 2438mm x 2591mm (external)

2

Floor Panel

14# Channel steel main beams (galvanized)

Steel tube cross member

ISO shipping container corners

15 mm plywood

2mm PVC Floor 2mm

3

Roof panel

Galvanized cold-formed steel roof frame with gutter

Steel tube cross member

ISO shipping container corners

Painting

50mm EPS (Expanded Polystyrene) Foam for insulation

4

Removable pillar

Steel cold-formed pillar, well painted

Linked with roof and floor with screws

5

Wall

50mm color-coated steel-EPS sandwich panels

Linked with tongue-and-groove solution

6

Door (875mm x 2000mm)

50mm color-coated steel- sandwich panel

Aluminum door frame

Safety lock, stainless steel

7

Window (875mm x 1000mm)

PVC frame

Single glass

Fly wire

8

Electronics, water supply and drainage are according to the local law (additional cost)

9

Furniture and appliance are customized-made to your requirements(additional cost)
