2013 Newest Saip Tig Welding Machine TIG-200P Welding Machine Gas Solenoid Valve
US$ 100 - 300
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Zhejiang, China
Brand Name:
Saip
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
2013 Newest Saip Tig Welding Machine TIG-200P Giant Weld MachineUS$ 100 - 300MOQ: 10 Pieces -
2013 Newest Saip Tig Welding Machine TIG-200P Plasma Welding MachineUS$ 100 - 300MOQ: 10 Pieces
-
2013 Newest Saip Tig Welding Machine TIG-200P Inverter Welding Machine CircuitUS$ 100 - 300MOQ: 10 Pieces
-
2013 Newest Saip Tig Welding Machine TIG-200P Rolling Welding MachineUS$ 100 - 300MOQ: 10 Pieces
-
2013 Newest Saip Tig Welding Machine TIG-200P Longitudinal Welding MachineUS$ 100 - 300MOQ: 10 Pieces
Condition
New
Place of Origin
Zhejiang, China
Brand Name
Saip
Model Number
TIG-200P
Arc Current
10-200
Pulse Frequency
50
Pilot Arc Current
10.1
Rated Duty Cycle
89%
Motor Type
DC Motor
Dimensions
640*400*510
Usage
for civil use
Voltage
220V
Power(W)
6.6KW
Certification
CE TUV ROHS
Warranty
One year
After-sales Service Provided
Overseas service center available
Specifications
1.efficiency can reach 80%2.easy and simple to operate
pact and portable
4.ac/dc
5.small spot welding machine
2013 newest saip tig welding machine TIG-200P
Specifications
1.plastic panl design
2.efficiency can reach 80%
3.small splashing, great penetration
4.adjustable voltage
5.Low noise
pper wire welding machine
Brief introduction
MOSFET Type
- MOSFET inverter circuit, high frequency arc starting
- AC square wave is specially suitable for welding aluminum and aluminum alloy products
- DC function for welding stainless steel, alloy steel, carbon steel, copper and other non-ferrous metal
- Small splashing, great penetration, easy and simple to operate and aesthetic appearance of weld seam
- Foot pedal is optional
Technical specification
| Inverter TIG-AC/DC Square Wave Welding Machine | |||
| Model | TIG-200AC/DC | TIG-250AC/DC | TIG-315AC/DC |
| Type | MOSFET | ||
| Rated input voltage (V) | single phase 220V±15% | three phase 380V±15% | |
| Rated frequency (Hz) | 50/60 | ||
| Rated input current (A) | 24 | 9.6 | 11.4 |
| No-load voltage (V) | 56 | 45 | 45 |
| Output current (A) | 10-160 | 10-250 | 10-280 |
| Pre-flow time (s) | 0-2 | ||
| Gas delay time (s) | 2-10 | ||
| Duty ratio | 20%-80% | ||
| Decay time (s) | 0-5 | ||
| Duty cycle (%) | 60 | ||
| No-load loss (W) | 60 | ||
| Arc starting | high frequency arc starting | ||
| Efficiency (%) | 85 | ||
| Power factor | 0.93 | ||
| Insulation grade | F | ||
| Protection grade | IP21 | ||
| Net weight (KG) | 23.4 | 31.2 | 31.2 |
| Dimension of packing (mm) | 640×400×510 | 640×400×510 | 640×400×510 |
Compared with traditional welding machine
Product display
Packing Show
Including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, TIG torch×1set
(air cooled WP-26 for TIG-200AC/DC & TIG-250AC/DC; water cooled WP-18 for TIG-315AC/DC)
...
