2013 New Low Cost Co2 Welder Machine Price MIG-250F

Name: 2013 New Low Cost Co2 Welder Machine Price MIG-250F
Brand: SAIP
SKU: 129512053

US$ 480 - 700 MOQ: 5 Pieces

Key Specifications

Condition:

New

Place of Origin:

Zhejiang, China

Brand Name:

SAIP

Yueqing Saip Electric Company Limited

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai or other china mianland port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Zhejiang, China

Brand Name SAIP

Model Number MIG-250F

Arc Current 220A

Motor Type AC Motor

Dimensions 500*210*370

Usage for civil use

Voltage AC380 ±15%

Certification CE

Warranty 1 year

Specifications

1.plastic panl design
2.efficiency can reach 80%
3.small splashing, great penetration
4.adjustable voltage
4.Low noise

2013 New low cost co2 welder machine price MIG-250F

Brief introduction

MOSFET Type

Suitable for welding metal plate with thickness above 0.8mm
Low cost but with high efficiency
Both output current and voltage could be adjustable to satisfy different welding requirement
Small splashing, great penetration
Two options of wire feeder: built-in or separated

Technical specification

Inverter CO2 Gas Shielded Welding Machine
Model	MIG-200Y	MIG-250Y	MIG-200F	MIG-250F
Type	MOSFET
Rated input voltage (V)	single phase AC220 ±15%	three phase AC380 ±15%	single phase AC220 ±15%	three phase AC380 ±15%
Rated frequency (Hz)	50/60
Rated input current (A)	23.5	10.5	23.5	10.5
Output current (A)	180	220	180	220
Output voltage (V)	23	25	23	25
Duty cycle (%)	60	60	60	60
Efficiency (%)	85	85	85	85
Power factor	0.93	0.93	0.93	0.93
Diameter of wire (mm2)	0.8	1.0	0.8	1.0
Type of wire feeder	built-in	built-in	separated	separated
Net weight of machine(KG)	33.7	35.2	11.9	13.7
Gross weight of machine packing(KG)	40	41.3	13	14.8
Gross weight of accessories packing (KG)	—	—	16.3	16.3
Dimension of machine (mm)	630×315×695	630×315×695	500×210×370	500×210×370
Dimension of packing- machine (mm)	660×370×750	660×370×750	560×270×460	560×270×460
Dimension of packing-wire feeder (mm)	—	—	555×435×410	555×435×410
including accessories: earth clamp×1pcs, cable joint×1pcs, grounding cable×3meters, pressure regulator×1pcs, MIG torch×1pcs,
additional accessories for MIG-200F/MIG-250F: double drive wire feeder×1pcs, control cable×5meters
