Home > Products > Transformer > variac transformer 500va
variac transformer 500va
- 10000 Set / Sets per Month
- ningbo/shanghai
- T/T Credit Card
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | Saip | Model Number: | BK |
Usage: | Other, control transformer | Phase: | Single | Coil Structure: | Toroidal |
Coil Number: | Autotransformer |
Packaging Details
standard export package
Product Description
Specifications
variac transformerElevator Transformer apply to be used as control power, working light of general electric applia
variac transformer
machine tool control transformers apply to be used as control power, working light of general electric appliance and mechanical equipment of various trades, and power of signal lamp with AC50-60HZ, input voltage doesn’t exceed 500V, output voltage doesn’t exceed 220V.
NP1 Series transformer | |||||||||
Type | Rated power (VA) | Rated input voltage(V) | Rated output voltage(V) | ||||||
NP1-40 | 40 | Control | illumination | indication | |||||
NP1-63 | 63 | 220±5% | 110(127) | 24(36) | 6(12) | ||||
NP1-100 | 100 | ||||||||
NP1-160 | 160 | ||||||||
NP1-250 | 250 | ||||||||
NP1-300 | 300 | ||||||||
NP1-400 | 400 | ||||||||
NP1-630 | 630 | ||||||||
NP1-800 | 800 | ||||||||
NP1-1000 | 1000 | ||||||||
NP1-1600 | 1600 | Distribution of capacity for different windings | |||||||
NP1-2500 | 2500 | would be according to the users requirements |
Type | Rated power (VA) | Installing dimensions | Outline dimensions | Cavity | |||||
A | C | B | D | E | F | K or K×J | |||
NP1-40 | 40 | 56±0.5 | 51±2 | 78 | 70 | 86 | 2 | 4.8×9 | |
NP1-63 | 63 | 56±0.5 | 51±2 | 78 | 70 | 86 | 2 | 4.8×9 | |
NP1-100 | 100 | 64±0.5 | 67±2 | 85 | 85 | 93 | 2 | 4.8×9 | |
NP1-160 | 160 | 84±0.5 | 74±2 | 96 | 90 | 103 | 2 | 5.8×11 | |
NP1-250 | 250 | 84±0.5 | 88±2 | 96 | 105 | 103 | 2 | 5.8×11 | |
NP1-300 | 300 | 84±0.5 | 96±2 | 96 | 115 | 103 | 2 | 5.8×11 | |
NP1-400 | 400 | 90±0.5 | 90±2 | 120 | 113 | 123 | 2.5 | 7×13 | |
NP1-630 | 630 | 122±0.5 | 86±2 | 150 | 118 | 145 | 2.5 | 7×13 | |
NP1-800 | 800 | 122±0.5 | 100±2 | 150 | 128 | 145 | 2.5 | 7×13 | |
NP1-1000 | 1000 | 127.5±2 | 152±2 | 155 | 205 | 145 | 3 | 7×12 | |
NP1-1600 | 1600 | 140±2 | 176±2 | 180 | 230 | 160 | 3 | 7×12 | |
NP1-2500 | 2500 | 173±2 | 200±2 | 205 | 260 | 175 | 4 | 7×12 |
NEW silicon steel sheet
Mark
Terminal
Company Profile
Our company (called "Saip" for short) is an enterprise specialized in the design, production and sales of electric equipment. Our office is located in the largest manufacturing base of electric equipment of Wenzhou, which is called "the Electric Equipment Capital of China".
Saip has five specialized branches, and over 300 specialized cooperative partners. Saip, an ISO9001 certificated enterprise, has modern production lines and high quality controlling equipment with scientific administration, professional engineers, highly trained teams, technicians and skilled workers.
Now, Saip has five design and production bases in Hong Kong, Taiwan, Singapore, Turkey and Wenzhou (China Mainland) respectively, 28 sales organizations in the world and more than 50 holding member enterprises.
Saip products cover low-voltage apparatus, welding equipment, instruments and meters, photoelectrons, and electrical products for construction, automobile apparatus and industrial automation. The products are sold to more than 100 countries and regions. All exported products have passed the certification of CE and partial products have passed several kinds of international certifications like RoHS, TUV, UL, KEMA, S, SIRIM and so on. Saip as always insists on the tenet of "high quality and sincere service".
Saip will be your successful cooperative partner.
