Bottle unscrambler
The bottle unscrambler's working principle is to arrange the empty PET bottles in turn through centrifugal force and orientation bottle drop device and send them out to connect with air conveyor system.
The bottle unscrambler is composed of round silo, umbrella tower, bottle drop device, and drive system. In addition, bottle elevator is equipped to send the empty PET bottles to the top of main machine. On the unscramble there is senor which controls bottles storage quantity the bottle in the main machine.
Technical features
It could handle different bottles according to customer's need.
The PLC control with frequency adjusting ensures the synchronization of the production line.
Bottle out feed is controlled by synchronous belt and starwheel to ensure stable bottle outfeed, no fallen bottles and no bottle squeezing.
Centralized lubrication system is set for lubrication at right time and right place with right dosing.
Technical Parameter
| Item | LP-16 | LP-18 | LP-21 | LP-24 |
| Working position | 16 | 18 | 21 | 24 |
| Productivity (BPH) | 6000-8000 | 8000-12000 | 12000-15000 | 15000-18000 |
| Air pressure | 0.7MPa | 0.7MPa | 0.7MPa | 0.7MPa |
| Power | 1.5KW | 3KW | 3KW | 3KW |
| Bottle range | D 50-100mm; H 165-310mm |
D 50-100mm; H 165-310mm |
D 50-100mm; H 165-310mm |
D 50-100mm; H 165-310mm |
| Dimension | Φ2240(D)×2200(H) | Φ2640(D)×2300(H) | Φ3020(D)×2650(H) | Φ3400(D)×2650(H) |
| Total weight | 3500KG | 4000KG | 4500KG | 5000KG |
