hot sale zhangjiagang water bottling machine

FOB Price

USD $20,000 - $23,000 / Set

1 Set(Min.Order)

Supply Ability 10 Unit / Units per Month
Port shanghai port
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Application:	Beverage, Food	Packaging Type:	Bottles
Packaging Material:	Plastic	Automatic Grade:	Automatic	Driven Type:	Electric
Voltage:	380V 50Hz	Power:	3.5kw	Place of Origin:	Jiangsu, China
Brand Name:	ERUSUN	Model Number:	RGFC24-24-8	Dimension(LWH):	300022002650mm
Weight:	5000KG	Certification:	CE ISO	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

1,The air conveyor is directly connected with bottle-in star wheel. The bottle is transferred by neck holding.
2,High speed filling line is of clamp transferring technology. Bottle shapes are more varied, and the working table inside the machine is more laconic.
3,By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, bottle changing is easier.
4,Specially designed stainless steel bottle clamp dose not contact the thread parts of the bottle neck, avoiding the second contamination.
5,The high speed line is of ring type pressure bearing hydraulic cylinder.
6,High speed and large flow filling valve assures the high filling speed and exact fluid level.
7,Spares contact with the liquid are all of excellent stainless steel or food level plastic. The electric system is of international brand and achieves the national food sanitary standard.
8,The bottle-out star wheel is of screw down shape. When bottle size is changed, there is no need to adjust the transferring chain's height.

Product Description

Technical features:

It is adopted that direct connection between air conveyor and inlet starwheel instead of screw and conveyor chains, which is easier for bottle changing.

There is no need to adjust the height of equipments through neck holding tech for bottle transportation.And what is only to change some spare parts.

High speed filling line is of clamp transferring technology.Bottle shapes are more varied, and the working table inside the machine is more laconic.

By 3-in-1 monoblock, the bottle goes through rinsing, filling and capping with little abrasion, and the transferring is stable, bottle changing is easier.

Specially designed stainless steel bottle clamp dose not contact the thread parts of the bottle neck, avoiding the second contamination.

High speed and large flow filling valve assures the high filling speed and exact fluid level.

Parts contact with the liquid are all of excellent stainless steel or food level plastic.The electric system is of international brand and achieves the national food sanitary standard.

The bottle-out starwheel is of screwdown shape.When bottle size is changed, there is no need to adjust the transferring chain's height.

Basic specification:
3-in-1 monoblock is composed of rinser, filler, capper, frame, sealing window, main motor and transferring system, cap unscrambler and electric control system etc.

The overturning device of the rinser is mainly composed of water distributor, bottle clamp, up turnplate, guide rail, protection cover, spraying device, defrosting tray.

Filling device is mainly composed of filling tank, filling valve, guide rail, elevating device, elevating device, etc.

Capping device is composed of cap unscrambler, cap drop rail and capper.

The assistant equipments include rinsing water recycle tank, bottle-in conveyor and bottle-out chain conveyor.Besides that, according to the customer's requirement, the machine could be equipped with manual bottle loader (or bottle unscrambling), manual bottle arranging multichain, automatic cap feeder and so on.

RGFC24/24/8 three-in-one machine for PET bottle integrates the function of rinsing, filling and capping together.Based on advanced technology overseas and designed according to the filling processing demands of natural mineral water, pure water, mineralized water and etc.

Technical parameters
Model:RGFC24/24/8

Amount of working position:Rinsing 24, filling 24, capping 8.

Production capacity:10000BPH - 12000BPH (500ML)

Pressure of air source:0.7Mpa

Air consumption:0.8M3/min

Pressure of rinse water:0.2~0.25MPa

Consumption of rinsing water:1.2t/hour (can be adjusted)

Filling pressure:0.2-0.3Mpa

Suitable bottle size:H:150-340mm, D:Φ 50-110mm

Total power:4.5KW

Weight:4000kg

Dimension:3000mm× 2200mm× 2800mm (L*W*H)

TECHNICAL DATA

Model	RGFC16/12/6	RGFC18/18/6	RGFC24/24/8	RGFC32/32/10	RGFC40/40/12	RGFC50/50/15	RGFC60/60/15	RGF72/72/18	RGFC80/80/22
Rinsing Head	16	18	24	32	40	50	60	72	80
Filling Head	12	18	24	32	40	50	60	72	80
Capping Head	6	6	8	10	12	15	15	18	22
Capacity (500ml)	3000BPH	8000BPH	12000BPH	15000BPH	18000BPH	21000BPH	24000BPH	27000BPH	30000BPH
Pressure of air source	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa
Air consumption	0.25M3/min	0.8M3/min	0.8M3/min	0.8M3/min	0.8M3/min	1M3/min	1M3/min	1.2M3/min	1.2M3/min
Pressure of rinse water	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa
Consumption of rinsing water	1t/hour	1.2t/hour	1.2t/hour	2t/hour	2t/hour	3t/hour	4t/hour	5t/hour	5.5t/hour
Filling pressure	0.2-0.3MPa	0.2-0.3MPa	0.2-0.3MPa	0.2-0.3MPa	0.2-0.3MPa	0.2-0.3MPa	0.2-0.3MPa	0.2-0.3MPa	0.2-0.3MPa
Suitable bottle size	H:150-300mm	H:150-340mm; D:Φ50-110mm; can be customized
Power	2.5KW	3.5KW	4.5KW	5.6KW	6.3KW	7.5KW	11KW	15KW	19KW
Weight	2500KG	3000KG	4000KG	5000KG	6000KG	7500KG	8500KG	10000KG	12000KG
Packing Size (LWH)(mm)	2200×1800×2300	2300×2000×2300	3000×2200×2800	4000×2600×2800	4700×2950×2800	5100×4800×3000	6200×4950×3000	7000×5500×3000	7800×6400×300
