Mini Electronic Speed Control ESC for 250 300 Multirotor Quadctoper

Mini electronic speed control ESC for 250 300 multirotor quadctoper

Multiaxial super small plate 20A ESC is designed to reduce the multi-rotor aircraft weight, increase multi-rotor aircraft load.

Features:

• Automatic detect the quantity of lithium batteries
• Automatic adjust the motor's timing
• low-voltage protection
• Free set up, it is usable when it is received
• Support Battery type: Lithium battery (Lipo), nickel metal hydride (NiMh), nickel cadmium (NiCd) batteries

• Anti-interference ability: well-designed circuit boards of high anti-interference, stable operation in a complex environment, avoid flying "accident."
• Six non-polar electrolytic capacitor capacitance replaces standard on ESC. Super light only 5G, small volume.
• Support 5V / 0.5A UBEC output, sustained and stable supply power 5V / 0.5A to servo. Easy to cancel BEC output: just disconnect the positive (red line) on ESC to cancel BEC output, and for only  signal line.
• Fast response, low heat emission. Adopt famous brands MCU control chip, full-N-pole MOS, enhance throttle response speed. The internal resistance of power output is only 0.01, reduce dissipation and increase efficiency.
• Automatic adjustment timing, compatible with most of brushless motor in market, application for 250, 300 multi-rotor aircraft.

Specification:

• Continuous operating current: 20A
• Burst current: 30A (10 seconds)
• BEC Output Type: UBEC
• BEC Output: 5.V / 0.5A
• Support battery: 2-4S
• Size: 27mm * 14mm * 5mm (no include cable)
• Weight: 5g (no include cable)
•
