Home > Products > plastic injection machine > Cheapest price plastic bottle preform injection molding machine
Cheapest price plastic bottle preform injection molding machine
- 100 Set / Sets per Month
- shanghai
- T/T Credit Card
You May Like
-
Factory price plastic bottle injection moulding machine
-
Best quality plastic bottle injection machine
-
CE standard Automatic plastic bottle injection molding machine
-
Automatic High Quality Plastic Bottle Preform Injection Moulding Machine Price
-
The Professional Plastic Bottle Preform Injection Moulding Machine
-
China Erusun plastic bottle preform injection moulding machine
Product Details
Condition | New | Application | Other, bottle | |
Packaging Type | Bottles | Packaging Material | Plastic | |
Automatic Grade | Automatic | Driven Type | Electric | |
Voltage | 220v/380v | Power | 17.5KW | |
Place of Origin | Jiangsu, China | Brand Name | ERUSUN | |
Model Number | YLS-3850A | Dimension(L*W*H) | 1.8*1.5*1.8m, 1.0*0.8*2.2m | |
Weight | - | Certification | CE ISO | |
After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Injection moulding machine Adopting Europe technology,hydraulic unit adopts proportional pressure and flow control,the pressure and the speed can be adjusted,stable movement curve and gentle shock,the computer is imported from Industry family. The LCD displaying screen with high clarity has Chinese and English language to use. Close-loop PID temperature control with the advantage of high precision. The operating table of the injection moulding machine have two safety, one is machine safety, another is electrical safety, that ensures the operator’s safety.
Mould Our mould producing center produces exact mould ,adopts the high grade material to make. The perform mould uses the hot runner technology, inside uses the imported steel, the surface’s brightness is very high and the service time is very long.
Characteristics of the production line:
1.The design of equipment is logical, easily operation.
2. The automatic level is very high, the wage is very little.
3.Using famous imported hydraulic, electrical, sealing parts, the trouble is low.
4.No matter what the product’s outside or inside, they can get the best guarantee, the good products rate can be above 99%.
Technical Parameter
MODEL | YLS-3850A | |
INJECTION UNIT | A | |
Screw diameter | mm | 63 |
Shot size(theoretical) | Cm³ | 1120 |
Shot weight | g | 1008 |
Injection pressure | Mpa | 175 |
Injection rate | g/s | 320 |
Screw L/D ratio | L/D | 22.7 |
Screw speed | r.p.m | 0-160 |
Nozzle Diameter | Srmm | 20 |
CLAMPING | ||
Clamp tonnage | KN | 3850 |
Toggle stroke | mm | 660 |
Mould Thickness | mm | 280-680 |
Space between tie-bars | mm | 680x680 |
Ejector stroke | mm | 160 |
Ejector tonnage | KN | 80 |
Ejector number | Piece | 13 |
Hole Diameter | mm | 160 |
OTHERS | ||
Heat power | KW | 17.5 |
Max. pump pressure | Mpa | 16 |
Pump motor power | KW | 30 |
Valve Size | mm | 25 |
Machine dimension | m | 7.0x2.2x2.0 |
Machine weight | t | 11.5 |
Oil tank capacity | L | 400 |
