Help CenterHot Selling Panasonic System Sleeve Laebling Machine
Related Products
-
Automatic Bottle Sleeve Labeling Machine for Bottle Customized MachineUS$ 12,900 - 36,500MOQ: 1 Set -
Hot Sale Bottle Neck Automatic Heat Shrink Sleeve Label MachineUS$ 12,900 - 36,500MOQ: 1 Set
-
Automatic Sleeve Label Shrink Machine for BottleUS$ 12,900 - 36,500MOQ: 1 Set
-
Pet Bottle Shrink Sleeve Labeling MachineUS$ 12,900 - 36,500MOQ: 1 Set
-
Full-Automatic Bottled Water Sleeve Labeling Machine,bottle Labeler , Plastic Labeling MachineUS$ 12,900 - 36,500MOQ: 1 Set
This machine adopts intermational advanced technology;cover the circle label on the pet bottle.And then hot shrinking to fix on the position which bottle body is designed.
This machine"s structure is compact,and suitable for the production line of different direction and different height.
The machinery part adopts combination designing of modularization,and makes the machine reasonable.The height adjustment adopts motor fluctuating;it is convenient to replace the material.The special cutter head designing,make the film-rolling cut more exactiy and reliably.
Feature:
1. Advanced technology: Japan-made motor controls synchronous cutting system to ensure long use life of cutting tool and high precision label.
2. Highly effective production speed: 400-bottles/per minute (standard bottle) It can work with the production line or just work alone.
3. Label-controlling sensor shelf
4. Elastic choice: The machine head can be leaned to fit round bottle, square bottle, elliptic bottle, top of bottle and body of bottle. The latest double material-providing system is applied to change material alternately with less time.
5. A unique synchronous cutting base: The cutting base doesn't need changing within the range of specification. If the specification needs changing, it can be done within five minutes.
6. Simple and safe operation: A colored people-controlling operation is used with both English and Chinese versions on it.
7. Low-consumption maintenance cost: low-cost abandoned blade for easy change.
8. Long use life of cutting tools: steel-connecting transmission mechanism, reciprocating cutting and prolonged use life.
Technical Parameter
| Model | YLS-100,200,300,400,500 |
| Main engine size (length*width*height) | 2000L x 950W x 2000H(mm) |
| Main engine production speed | 10-400BPM |
| Main engine power supply | AC 3phase220v/380v |
| Bottle/Can Flat Width | 48 -185mm |
| Bottle/can materials | Glass,metal,plastic |
| Label length | 25mm -280mm |
| Label thickness | 0.03mm -0.13mm |
| Label material | PVC.PET.OPS |
| Bottle/can height | 15mm -320mm |
| Bottle/can diameter | 30.5mm -120mm |
| Bottle/can shape | round,square,oval,rectangular |
| Main engine weight | 5 00kg |
