Home > Products > DENTAL X-RAY UNIT > Panoramic Dental X-Ray Machine AP-90
Panoramic Dental X-Ray Machine AP-90
- Shanghai China
- T/T Credit Card
You May Like
Product Details
| Properties | Other, Medical X-ray Equipments & Accessories | Brand Name | JPS | |
| Model Number | AP-90 | Place of Origin | Shanghai, China |
Product Description
Specifications
PANORAMIC DENTAL X-RAY MACHINE1. DIGITAL STANDARD DESIGN
2. THREE POSITIONING LASER BEAMS
3. AUTOMATIC VOICE GUIDANCE
4. CE
PANORAMIC DENTAL X-RAY MACHINE AP-90
JPS Panoramic Dental X-Ray Machine is most used in dental clinics, dental offices and hospitals; it should be used by trained dentists, dentist assistants and technicians. It possesses stable structure, fashion appearance, easy operation, high reliability and it is very safe which make it the best choice for dentists and doctors.
Our Panoramic Dental X-Ray Machine is high voltage generator but with a minimum radiation for the patient, itcan radiograph a complete view of the curvature of the whole teeth in a picture, the picture includes sinuses, nasal sinus, maxillary, mandibular structure and the whole 32 teeth, temporal, lower jaw joint and its combined relations. Finally, it has eight panoramic modes and four cephalometric modes.
| Exposure Time (s) | Panoramic: 14 |
| Cephalometric: 0.2-3.2 | |
| Weight | 220 Kg |
| Power | 1.3 KW |
| Photographed Region | Panoramic: 146×300 mm |
| Cephalometric: 180×240mm | |
| Grayscale | 4096 (12 bit) |
| Exposure Factor | 50-90 KV, 2-10mA |
| 1 | Digital standard design: Much more accurate by using digital panoramic circuit upgrade to digital panorama easily and conveniently. |
| 2 | Three positioning laser beams: Adjustable canine beam ensures precise position. |
| 3 | Head auxiliary fixing device: Frontal and both sides of the temporal are fixed, ensuring patient's head stable. |
| 4 | Automatic voice guidance: Guidance for the whole process of x-ray exposure. |
| 5 | Convex positioning mirror: No deformation of patient's face, ensuring operator to position accurately and quickly. |
| 6 | The profile of face soft tissue can be displayed automatically: The device adjusts KV and mA automatically while scanning, ensuring that the profile of face soft tissue be displayed clealy. |
| Net Weight | 180 Kg |
| Gross Weight | 200 Kg |
| Size | 110×68×119cm; 167×99×80cm; 231×32×44cm |
