Home > Packaging & Printing > Packing Machinery > Filling Machine > High Technical Fruit Juice Processing Equipment
US$ 2,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage
Packaging Type:
Bottles
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fresh Fruit Juice Processing LineUS$ 2,000 - 50,000MOQ: 1 Set -
Bottle Fruit Juice Processing EquipmentUS$ 2,000 - 50,000MOQ: 1 Set
-
The Best Supplier Fruit Juice Processing EquipmentUS$ 2,000 - 50,000MOQ: 1 Set
-
Good Quality Juice Process MachineUS$ 2,000 - 50,000MOQ: 1 Set
-
Best Quality Fruit Juice Process EquipmentUS$ 2,000 - 50,000MOQ: 1 Set
Condition
New
Application
Beverage
Packaging Type
Bottles
Packaging Material
Glass
Automatic Grade
Automatic
Driven Type
Electric
Voltage
220V/380V
Power
3KW
Place of Origin
Jiangsu, China
Brand Name
ERUSUN
Dimension(L*W*H)
Customizable
Weight
100kg-5000kg
Certification
CE ISO
After-sales Service Provided
Engineers available to service machinery overseas
Model Number
Mixing Tank
Product Description
CIP system is the function of automatic cleaning of all product contact surface cleaning including tank wall and pipe wall, the inner wall of the cylinder, and other liquid channel.
CIP system is consist of cleaning fluid tank, acid and alkali adding device, heater, process and the reflux pump, pipeline, the steam valve group, etc.
The key technical parameters of the CIP system is cleaning fluid type, concentration, temperature and flow rate. Alkali liquor usually use NaOH, acid liquor use nitric acid or phosphoric acid, concentration1-3%, proper heating, the cleaning velocity between 1.5-3 m/s
Cleaning fluid storage tank usually have three: Acid tank, alkali liquor tank, hot water tank. Depending on the different cleaning object, it can be divided into single loop, double circuit, multi-loop, etc
Automatic CIP system of strong acid, strong alkali added, cleaning fluid temperature is automatic control, cleaning sequence is braking performed after setting.
Technical Parameter
| Full autoCIP | Cleaning In Place (CIP) | |
| Function | For tank, pipe, pump, and the whole production line (filling machine, pre-blending system)cleaning and disinfection | |
| Application Area | Widely used in food processing factory (milk, beverage, wine, etc) and liquid medicine factory,to meet the requirements of health andenvironment | |
| Equipment composition | CIP main composition (not including accessories) : acid tank, alkali tank, hot water tank, water tank, bracket, CIP pump, plate heat exchanger, steam regulating system, PID automatic temperature control system, check/control system, main control cabinet (stainless steel) | |
| Combination property | safety performance | 1.Control valves and instruments adopted imported high quality components, to ensure the accuracy and stability of the system 2.In cleaning, completely sealed, no secondary pollution 3.High-tech of 360 ° universal rotating cleaner 4.Equipped with air breathing apparatus, quick-opening manhole 5.The mirror polishing treatment on the surface, the surface via the inferior smooth processing 6.Equipped witheight adjustable telescopic supporting feet, to ensure the stability of the equipment on the floor 7.Heat-proof/acid/alkali washer, to ensure the sealing performance |
| Energy-saving performance | 1.Users are free to choose the cleaning process, stability, time, equipment will be effected according to the users to set the automatic configuration of acid-base concentration 2.Equipped with the return water system, saving CIP water 3.Equipped with extracorporeal circulation system, effectively reduce energy consumption 4.Support the acid and alkali recovery | |
| Efficiency Performance | 1.Automatically set acid, alkali concentration 2.Equipped with PLC touch screen switch (SIEMENSTFT10.4 inches)display options, real-time temperature, time, electric conductivity, etc 3.Support the senior road cleaning, road, more than two not only supports two or more areas and at the same time cleaning, support also in the process of production production while cleaning, greatly reducing the CIP cleaning time 4.Cleaning fluid for automatic detection, charging, discharge, display and adjust 5.Through the scene changes, the freedom to choose automatic or manual control 6.Based on customer special requirements, the establishment and modify the program, special control | |
| Maintenance | 1.USES the unibody design, save the production space 2.Using the United States imported pneumatic diaphragm pump suction concentrated acid and concentrated alkali, at the same time reduce the operation cost and equipment maintenance rate | |
| Motor | 1.1 KW 2880R/MIN | |
| Weight | 300 KG | |
| Dimension (mm) (L×W×H) | 2700×1800×1200
| |
