110VAC single phase AVR automatic voltage regulator

110VAC single phase AVR automatic voltage regulator

Description:

SVC series of high-performance automatic AC regulated power supply,from auto-contact voltage regulator,servo motor,automatic control circuit etc.,when the grid voltage is unstable or load changes,automatic control circuit according to the output voltage change-driven servo motors,Auto-voltage is regulator to adjust contact position on the carbon brush,so that the output voltage is adjusted to the rated value,the output voltage is stable and reliable high efficiency,long continuous work.

In the grid voltage fluctuation large or seasonal variation in line voltage for use in are as will enable all kinds of loads,equipment,instruments,and household appliances can work properly.is well known that high voltage electrical burn damage to equipment,Air conditioners,refrigerators,etc.,when the voltage is too low is difficult to start,unable to work,power rather than start,or barely started and the voltage is too low will be air-conditioner,refrigerator compressor overcurrent burned,therefore,voltage is not a normal occasion,you must use the AC power supply,this product cheap.

Notes:

1,environmental conditions require a well-ventilated,non-corrosive gases,explosive substances,conductive dust and steam,etc.,without a strong vibration impact,heat and so on.

2,according to electrical equipment,power,startup surge current regulated power supply power to choose,etc.,there must be enough to cushion the impact of the load should not be used.

3,regular dust removal machine to keep gears,coils,car bon brush cleaning,long-term work,the carbon brush wear,we should adjust the carbon brush contact pressure with the coil to make good contact and avoid arcing.

4,grounding must be reliable and to ensure safety.

5,installation,wiring,adjustments charged work,mush have electrical knowledge of personnel to operate and avoid maintenance ,adjustment,electric shocks and accidental damage to power supply.

6,do not cover with plastic dust cover, in regulated power supply ,hinder power dissipation,caused by the power supply caused by overtheating.

7,to power generation,first source of power supply voltage regulator to switch off the generator in the normal,and then turn the power switch.

8,products with over-voltage protection,delay in the 4-10 seconds.

9,If necessary,the user adjustable,output voltage,control circuit boardof the variable potentiometer clockwise rotation,the output voltage rise,counter-clockwise rotation,the output voltage reduced.

Application:

  SVC(TND) series single-phase high precision full-auto AC voltage regulator adopts linear integrated circuit  form servo motor control system, drive the contact voltage regulator to regulate automatically by controlling the servo motor, it has excellent features,such as small wavefrom.distrotion,high power factor.free from the effector frequency variation of supply,it is used most situations where the electricity voltage fluctuation requirement

Service Occasions:

  Computer,Fax machince and office equipument,Test equipment,lighting equipment,Alarm and security system,X-Ray equipment,Medical equipment,Duplicator,Broadcasting equipment,Numeric control machine tool,Industrial robot,Photographic processing machine,Laboratory instrument HI-FI.

Q 1. What's the payment term?

A. We accept TT,Western Union,Paypal,MoneyGram.

Q 2.How's the delivery time ?

A. Is due to order quantity, usually it will take about 3-7days for sample production,

Q 3.Tell me the standard of package?

A. For the small capacity, it use carton, but for big capacity, we should use honeycomb carton and pallet or  wooden case for protection.

Q 4.Would you accept to use our logo ?

A.It's no problem to do OEM.

Q 5.We want to know month capacity.

A. It depends on which model.For example for relay type small capacity , month capacity can reach near 2000pcs  and big capacity near 500pcs.

Q 6.Where is your market?

A. Our products are popular in Australia,South America,Philippines,Italy, America, Pakistan and so on.Some of them are our regular customers and some of them are developing. We hope you can join us and make mutural benifit from our cooperation.

Q 7. What kind of certificate you have ?

A. Our company already achieve ISO9001, and for products, we have CE, SAA, G83 G59 etc .

OEM Services
1.Logo
Please offer us your own high resolution logo in JPG format,there should be two colors at most in the logo and there should be no gradient effect in the logo.
2.Label
Please offer us your own model numbers.
3. Manual
Please offer us the finished manual file that can be printed directly.

Lead Time
1.Sample orders will be delivered from our factory within 3-7 working days.

2.General orders will be delivered from our factory within 15-30working days.
3.Big orders will be delivered from our factory within 45 working days at most

Shipment
1.By EMS,DHL,FedEx,TNT,UPS or other express.

2.By our forwarding agent(by air or by sea).

3.By your own forwarding agent.
4.By domestic forwarding agents to any city in China.
