Deer series offline UPS 600VA/800VA/1500VA/2000VA
The ST Series is offline UPS with the most advanced DSP control technology which can protect the sensitive device from utility fail, over /under voltage, surges, transients, spikes and other electrical abnormalities. With automatic boot voltage regulation and wide input voltage range, ST is a good choice to be applied to all kinds of complex power environment.
Features:
1.Automatic booting when the utility recovers
2.Wide range of input voltage
3.Alarm and mute
4.Auto recharging
5.Overvoltage and circuit short protection
6.Interface of RJ45/11 and USB
Specification:
| Model | ST500 | ST600 | ST800 | ST1000 | ST1200 | ST1500 | ST2000 | ST3000 |
| Capacity | 500VA | 600VA | 800VA | 1000VA | 1200VA | 1500VA | 2000VA | 3000VA |
| Input Voltage | 110/120VAC or 220/230/240VAC | 220VAC | ||||||
| Input Voltage Range | 85~150VAC/145~290VAC | 175~275VAC | ||||||
| Input Frequency | 50/60Hz(Auto sensing) | 50Hz | ||||||
| Output Voltage | 110/120VAC or 220/230/240VAC | 220VAC | ||||||
| Output Voltage Range | 102-132VAC/200-255VAC | 200~240VAC | ||||||
| Output Frequency | 50/60Hz±0.5Hz | 50Hz±0.5Hz | ||||||
| Wave Form | PWM (DC mode) | PWM(DC mode) | ||||||
| Transfer Time | Typical 2-6ms,Max<=10ms | <=10ms | ||||||
| capacity of battery | 1*12V/4.5AH | 1*12V/7AH | 1*12V/9AH | 2*12V/7AH | 2*12V/7.5AH | 2*12V/9AH | 4*12V/7AH | 4*12V/9AH |
| Charging period | 4~6h to 90% capacity | 10~16hours | ||||||
| Protection | Low voltage, overload and short circuit protection | |||||||
| Operation Temperature | 0~40ºC, | |||||||
| Humidity | 20%~90%(non-condensing) | 20%~90%(non-condensing) | ||||||
| Noise | ≤40dB | |||||||
| Net Weight(Kg) | 4 | 5.5 | 6 | 10.2 | 10.2 | 10.6 | 19 | 21 |
| Dimension | 250*95*140 | 305*85*140 | 335*118*190 | 340*110*265 | 408*145*220 | |||
| Optional |
LED/LCD,RJ45/11&USB |
|||||||
