2KVA High Frequency Online UPS Pure Sine Wave Output

Name: 2KVA High Frequency Online UPS Pure Sine Wave Output
Brand: JETPOWER
SKU: 129451121
Availability: InStock

US$ 255 - 290 MOQ: 1 Unit

Key Specifications

Place of Origin:

Shandong, China

Brand Name:

JETPOWER

Model Number:

PT-2KS

Qingdao Powtech Electronics Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Shandong, China

Brand Name JETPOWER

Model Number PT-2KS

Phase Single Phase

Protection Overvoltage

Weight 22.7kg

Output Voltage 208/220/230/240VAC

Type On-line

Application Telecommunications

2KVA high frequency single phase online UPS/Dragon-II series pure sine wave UPS

Product Description

2KVA online UPS/Dragon-II series

Model:PT-2KS

Technical Specifications:

Model		2KS
Capacity	Capacity	2KVA/1600W
	Nominal Voltage	208/220/230/240VAC Single phase 2 wire+G
	Nominal Frequency	50/60HZ (auto sensing)
Input	Voltage Range	115~300VAC
	Frequency Range	50HZ: (46~54HZ); 60HZ:(56HZ~64HZ)
	Power Factor	> 0.98
Output	Voltage Precision	208/220/230/240X 1( ±2%)VAC
	Frequency Precision	50/60Hz ±0.05Hz
	Power Factor	0.8
	Harmonic Distortion	Linear load<3% Non-linear<6%
	Overload Capacity	load > 110% for 47s; load > 150% for 25s; load > 200% for 300ms;
	Current Crest Ratio	3:1
	Transfer time	0 ms(AC mode↔DC mode);(AC mode↔Bypass<4ms)
Battery	DC Voltage	72VDC
Battery	Recharge Time	5 hours to 90%(it means standard model which battery inside UPS)
Panel Display	LCD	UPS status, input/output voltage and frequency, battery voltage, capacity, load temperature, history records, adjust voltage, ECO mode
Panel Display	Communication port	RS232, SNMP Card(Optional),USB port(Optional)
Working Environment	Temperature	0 ºC~ 40 ºC
	Relative Humidity	0~95%(Non-condensing)
	Elevation	1500 m
	Noise Level	<45dB
Physics Characteristic	Net weight(kg)	22.7
Physics Characteristic	Dimension:(WxDxH,mm)	330170400
