2000W Solar System Grid Tie Invertors
- Ningbo or Shanghai or Shengzhen
- Credit Card
You May Like
-
300kw Large Power Inverter for Solar Power System
-
20kw Single Phase or Three Phase Output Grid Tie Inverter
-
Two Solar Inputs Single Phase 5000w Grid Tie Inverter
-
BZS 250KW Wind Turbine Grid-tied Converter
-
Low Frequency Transformer Wind Grid Tie Inverter 250kw
-
Hot Selling BZS 500KW Solar System Gird Tie Inverter
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Bangzhao or OEM | |
| Model Number | BZS-2KW | Output Power | 1 - 200KW | |
| Output Type | Single | Size | 442*380*110mm | |
| Weight | 22kg | Input Voltage | 100-500vdc | |
| Output Voltage | 110V/220V/230V/240V | Type | DC/AC Inverters | |
| Output Frequency | 50Hz/60Hz | Output Current | 9A |
Product Description
2000W solar system grid tie invertors
Using the fifth generation lntellingent Power Module from Mitsubishi,
Improve the system efficiency higher
High conversion efficiency
Advanced technology for maximum power point tracking(MPPT)
(>97%)MPPT efficiency
Wide input voltage range
High reliability due to compltte protection function
Powerful communication interfaces
Easy operation and installation
Easy-to-set multilingual LCD display
Adjustable protection / operation parameters
Model | BZS-2000W | |
Isolation type | Transformerless | |
DC Input | MPPT Voltage Range | DC100~500V |
Max. DC Voltage | 500VDC | |
Start Voltage | 180V | |
Recommend PV Array Open Circuit Voltage | 200~400V | |
Control System | MPPT | |
Number of MPPT Tracker | 2 | |
AC Output | Rated Output Power | 2000W |
Max. AC Output Current | 9A | |
Rated Grid Voltage | 230VAC | |
Grid Voltage range | AC 180~270V (1 phase) | |
Normal Grid Frequency | 50/60Hz(Grid frequency) | |
Phases | 1 phase 2 wire | |
Power Factor | >0.95 | |
Current THD | At rated power and in the sine wave <5% | |
Control System | PWM | |
Anti-islanding | ≤0.5 sec | |
Output Overload | 100% | |
Max. Efficiency | 98% | |
Euro Efficiency | 97% | |
Structure | Protection Class | IP65 |
Cooling system | Natural cooling | |
Power Consumption at Night | 0W | |
Noise | <25dB | |
Data Interfaces | External RS232C/RS485 | |
Display | LCD | |
Dimensions(W*H*D) | 442*380*110mm | |
Weight | 15.5kgs | |
Protection | Inverter | Input overvoltage, output short circuit, overheat, output DC component. |
Grid | Anti-islanding, over/under voltage of grid, over/under frequency of grid. | |
Environment | Environment | No corrosion gas, flammable gas, oil mist, dust etc. |
Operation temperature | -10℃~40℃(50℃) | |
Stored temperature | -20℃~65℃ | |
Relative humidity | 0~100% (Do not wet with dew) | |
CE-Standards Complied | CE-Standards Complied: EN61000-6-2, EN61000-6-4(EMC), EN61558-1, EN61558-2-17, EN50178, EN61000-1, | |
Certifications | CE, AS4777, AS3100, G83/1, G59. ISO9001:2000 | |
