Pure Sine Wave Inverter (ISO, CE Certified)
US$ 150 - 180
MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Jetpower
Model Number:
ND110-1020
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
1kva Pure Sine Wave Inverter (ISO, CE Certified)US$ 180 - 200MOQ: 1 Unit -
1-10K Home InverterUS$ 300 - 1,000MOQ: 1 Piece
-
HI Series /1-10K Inverter for Home Power SupplyUS$ 300 - 1,000MOQ: 1 Piece
-
110V DC/AC 30KVA InverterNegotiableMOQ: 50 Units
-
220VDC/AC 3kva InverterNegotiableMOQ: 50 Units
Place of Origin
Shandong, China
Brand Name
Jetpower
Model Number
ND110-1020
Output Power
1 - 200KW
Output Type
Single
Size
440*450*177 mm
Weight
50kgs
Input Voltage
110Vdc
Output Voltage
220Vac,1 phase
Type
DC/AC Inverters
Output Frequency
50/60Hz
Output Current
9A
110VDC pure sine wave inverter
Product Description
Input: 110Vdc input
Output: 220Vac/1phase output
Capacity: 2kva/1.6kw
Our company is ISO9001 certified, and these products has passed CE test. We also provide 1year warranty with 5% free spare pars
Packaging & Shipping
Tech. specs
| 110VDC/AC inverter (1phase output) | |||||||||
| Model | ND 110 | ND 110 | ND 110 | ND 110 | ND 110 | ND 110 | ND 110 | ND 110 | |
| -1010 | -1020 | -1030 | -1050 | -1100 | -1200 | -1300 | -1500 | ||
| DC input | Rated DC input voltage (VDC) | 110VDC | |||||||
| Rated DC input current (A) | 10 | 20 | 32.6 | 50 | 98 | 198 | 296 | 494 | |
| DC input voltage range (VDC) | 180~300Vdc | ||||||||
| Bypass | Utility AC input voltage (VAC) | 220Vac±20%, 50Hz±10% | |||||||
| Utility | Rated AC input voltage (A) | 4.5 | 9 | 13.5 | 22.7 | 45 | 91 | 136 | 227 |
| input | Bypass transfer time (ms) | ≤4 | |||||||
| AC output | Rated capacity (KVA) | 1 | 2 | 3.0KVA | 5 | 10 | 20 | 30 | 50 |
| Rated output power (KW) | 0.8 | 1.6 | 2.4 | 4 | 8 | 16 | 24 | 40 | |
| Rated output voltage and frequency | 220VAC, 50HZ | ||||||||
| Rated output current (A) | 4.5 | 9 | 13.5 | 22.7 | 45 | 91 | 136 | 227 | |
| Output voltage regulation (V) | 220±2% | ||||||||
| Output frequency regulation(Hz) | 50±1% | ||||||||
| THD | ≤3% | ||||||||
| Dynamic response (load 0←→100%) | 5% | ||||||||
| Power factor | 0.8 | ||||||||
| Overload | 150%,60s | ||||||||
| Crest factor | 3:01 | ||||||||
| Efficiency at rated load | 90% | ||||||||
| Environment | Insulation strength (between input & output) | 1500VAC, 1min | |||||||
| Noise (1m) | ≤50dB | ||||||||
| Temperature | -10°C~+50°C | ||||||||
| Humidity | 0~90%, no condensation | ||||||||
| Altitude (m) | ≤2000 | ||||||||
| Sizes | Rack tye (W* D * H, mm) | 482×405×133 | 482×405×178 | 482×420×223 | 550×480×980 | ||||
| Weight (kg) | 18 | 30 | 40 | 60 | 150 | 260 | 360 | 700 | |
| Protection | DC input reversely protection, DC input under voltage, overload, short circuit, over temperature | ||||||||
