Specifications
1.Rotary device 300*2500mm2.With rotary device for 4D works
3.Strong frame for stone working
4.dustproof design
Hot new products for 2015 MITECH 4 axis rotary marble cnc machine
CNC machine features:
- Three axises adopt imported linear orbit, two line sliding track, heavy loading, stable working, high precision, longlife time.
- Whole seamless weld steel structure, not easy to distort, the table back lining is armor plate, good rigidity, the machine can bear 1 MT at least.
- Constant power spindle and motor for quickly stone processing or spindle for fast cutting aluminum sheet, strong cutting capacity, high efficiency,Well compatibility, compatible software CAD/CAM, such as Type3, Artcam, Castmate, Wentai, CorelDraw.
- Double direction cutters cooling stem can prolong the life time of using.
- Advanced 3D carve budget and stable broken line enables carving professional speed and precision .Advanced file pretreatment function can correct error in the files and compatible with the process cades of multiple national and internationa software
CNC machine parts:
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
2.2kw constant power spindle ensure nice work on the hard stone.With automatic water supply cooling system,avoid tool damage caused by the temperature too high.
-------------------------------------------------------------------------------------------------------------------
4 sets Rotary device 300*2500mm,for processing the cylindrical stone materials 4D works. Greatly improve the working efficiency useing for tombstone carving,granites,artificial stones processing.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
All dustproof and waterproof design,three axis of the machine with dust cover,protect the linear guide fron dust,increase the service life for transmit linear guide.
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------Advance control system can save 10 breakpoints, with a function that continue carving even
if has breakpoint.After stopping the electric, it can still working later, it can reduce the rate of rejection.
-------------------------------------------------------------------------------------------------------------------
Independent control cabinet more cleanly, convenient and safe.High-performance driven motor to ensure that the machines high speed and accuracy.Big Yako driver provide more power for motor,and Delta converter for Taiwan garantee the spindle have good work
-------------------------------------------------------------------------------------------------------------------
Along the cnc drouter machine with carved software,advanced file pretreatment function can correct the error in the files and is compatible with the process codes of multiple national and international software.(such as UCANCAM, Type3, Artcam).
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Package: Humidity-Proof Cloth Above Wooden Case, Multi-Layer Film Covered Machine Body, Oil Covered with Film on Machine Transmission, Steel Tubes On&Under Wooden Case.
-----------------------------------------------------------------------------------------------------------------------------------------------------------------------------
CNC machine Parameters:
| MITECH-3025 CNC router for stone Parameters | |
| Rotary Device | 300*2500mm |
| Z-Axis | 400mm |
| Body Dimension | 2100*3300mm |
| Spindle Power | 3kw constant watercooling spindle, 24000rpm |
| Machine Body | Ultra thicken steel tubes with quenching treatment |
| Repeatability | +/- 0.02mm |
| Working speed | 17m/min |
| Max. Rapid Travel Speed | 25m/min |
| Traverse system | Linear guide on 3 axis,rack and pinion on Y,ballscrew on Z |
| Motor | Stepper (servo optional) |
| Machine table | Coolant tray with wheels |
| Mist cooling system | Cooling nozzle and pump |
| Working voltage | 380V/220V ,3 phrase |
| Command language | G Code, PLT |
| Collet | ER25 |
CNC machine application:
1.Three-dimensional relief engraving for natural marbles, granites, artificial stones, tombstones, tean tables ink stones,milestones, ceramic tiles, glass and other materials, as well as two dimensional engraving for line line engraving,cutting,beveling and drilling
2. Marble,artificial stone,bone,ivory,state and other materials,pratical gifts to the ads,printed cartons,leather clothing ,building models,jade and other stone materials
CNC machine samples show:
Package:Humidity-Proof Cloth Above Wooden Case, Multi-Layer Film Covered Machine Body, Oil Covered with Film on Machine Transmission, Steel Tubes On&Under Wooden Case.
Shipping: Safetly and saving by sea distribute our machine to our partners and customers
We can send this machine to your port or door address by sea or by air. Do as you need.
If sending to your port, please tell us your port.
If sending to your door address, please tell us your address, and better with post code.
MITECH is a professional CNC machinery manufacturer.We are well known for our superior quality and service in the field of engineering and manufacturing of CNC and Laser Equipment that includes: CNC Router, CNC Woodworking machine, CNC Advertising Router Machine, Stone CNC Router, Metal CNC Router,Cutting Plotter, Sign Plotter, CO2 Laser Engraver, CO2 Laser Cutting Machine, PVC Concave-convex Sign card Machine and so on.
1. What's the guarantee, in case the machine breaks down?
The machine has one year s guarantee.We will offer at leaset 12 hours online service support.. Parts except for consumable parts will be replaced for free if the problems are caused by quality faul
2. How about the documents after shipment?
After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
3.How long is the delivery time?
For standard machines, it would be 10-15 days;
For nonstandard machines and customized machines according to client s specific requirements, it would be 25 to 35 days
4.How's the payment?
Our normal payment term is Telegraphic Transfer(T/T) , LC, Western Union, Escrow etc if this is not acceptable for you,please send emai for negotiate.
