2KVA/1.4KW home inverter/Pure sine wave inverter 1k,2k,3k,5k,6k,8k,10k/115v or 230v home ups inverter

Model

HI-1K

HI-2K

HI-3K

HI-5K

HI-6K

HI-8K

HI-10K

Capacity

1KVA/700W

2KVA/1.4KW

3KVA/2.1KW

5KVA/3.5KW

6KVA/4.2KW

8KVA/5.6KW

10KVA/7KW

Input

Nominal voltage

110/115/120Vac   or 220/230/240Vac

Voltage range

60~135Vac   or 145~275Vac

Frequency   range

45Hz~60Hz   Auto-sensing

Output

Nominal voltage

115Vac or   230Vac

Voltage regulation   (Bat. Mode)

<3% RMS   for entire battery voltage range

Frequency   Regulation

50Hz or   60Hz ±0.1Hz (Battery Mode)

Power   Factor

0.7

Wave Form

Pure Sine   wave

Efficiency

>80%

Overload protect

Line Mode

>110%,then   Buzzer Alarm

Battery Mode

>110%~150%   for 30 sec;>150% for 200ms,then inverter Shuts Down

Protective Measure

Line Mode

Circuit   Breaker

Battery Mode

Electronic   Circuit

DC Cold   Start

Yes

Transfer   Time

<2ms

Battery

Battery Voltage

24Vdc

24Vdc

24Vdc

48Vdc

48Vdc

48Vdc

48Vdc

Backup Time

Base on the   batteries connected

Recharging   Current

>20A

>25A

>25A

>30A

>50A

>50A

LCD Display

I/P&O/P   Voltage FREQUENCY, Load level, Battery Voltage & Level,

Audible   Alarm

Battery Mode

Beeping   4times every 20 second

Low Battery

Beeping   every second

UPS Fault

Beeping   Continuously

Overload

Beeping   twice per second

Environment

Operation   Temperature

0-40 degree   C; 32-104 degree F

Relative   Humidity

0-95%   non-condensing

Audible   Noise

Less than   50dBA(at 1M)

Physical

Size(W*D*H,mm)

430*300*89

430*415*132

430*415*132

210x 440x 340

210x 440x 340

300 x510 x790

Weight   (without battery)

14.8

17.7

21.5

38.3

38.3

60

80

Safety   Conformity

Safety   Standard

EN62040-1-1

EMC

EN62040-2

Marks

CE
