30K Parrallel Power Inverter/110V DC/AC 1 Phase Inverter (1K,2K,3K,4K,5K,10K,20K,30K,50K)/dc to ac Inverter 1 Phase/

FOB Price

US$ 800 - 1,000 / Unit

1 Unit(Min. Order)

Port Qingdao
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shandong, China	Brand Name	JETPOWER
Model Number	ND110-1300	Output Power	1 - 200KW
Output Type	Single	Size	380680935
Weight	360	Input Voltage	110Vdc
Output Voltage	220Vac	Type	DC/AC Inverters
Output Frequency	50/60Hz	Output Current	136A

Product Description

30KVA parrallel power inverter/110V DC/AC 1 phase inverter (1K,2K,3K,4K,5K,10K,20K,30K,50K)

Product Description

30KVA parrallel power inverter/110V DC/AC 1 phase inverter (1K,2K,3K,4K,5K,10K,20K,30K,50K)

Features:

1.Advance IGBT inverted technology

2.Multiple CPU intelligent control

3.Multiple protection function of over-voltage ,short circuit, over-temperature on input

4.Special industrial design to ensure the safety in worse environment

5.Reliable, filtering and stable sine wave output

6.Static bypass switch

7.With output isolation transformer

Tech. specs

110VDC/AC inverter (1phase output)
Model		ND 110	ND110	ND110	ND110	ND110	ND110	ND110	ND110	ND110
Model		-1010	-1020	-1030	-1040	-1050	-1100	-1200	-1300	-1500
DC input	Rated DC input voltage (V_DC)	110
	Rated DC input current (A)	5	10	16.3	21	25	49	99	148	247
	DC input voltage range (V_DC)	88~132Vdc
Bypass	Utility AC input voltage (V_AC)	220Vac±20%, 50Hz±10%
Utility	Rated AC input voltage (A)	4.5	9	13.5	18.5	22.7	45	91	136	227
input	Bypass transfer time (ms)	≤3S
AC output	Rated capacity (KVA)	1	2	3.0KVA	4	5	10	20	30	50
	Rated output power (KW)	0.8	1.6	2.4	3.2	4	8	16	24	40
	Rated output voltage and frequency	220V_AC, 50H_Z
	Rated output current (A)	4.5	9	13.5	18.5	22.7	45	91	136	227
	Output voltage regulation (V)	220Vac±2%
	Output frequency regulation(Hz)	50±1%
	THD	≤3%
	Dynamic response (load 0←→100%)	5%
	Power factor	0.8
	Overload	150%,60s
	Crest factor	03:01
	Efficiency at rated load	90%
Environment	Insulation strength (between input & output)	1500V_AC, 1min
	Noise (1m)	≤50dB
	Temperature	-10℃~+50℃
	Humidity	0~90%, no condensation
	Altitude (m)	≤2000
Sizes	Rack tye (W* D * H, mm)	440×450×177	440×450×177	440×450×177	440×500×221.5	440×500×221.5	330×640×885	380×680×935		490×985×1205
Weight (kg)		18	30	40	50	60	150	260	360	700
Protection		DC input reversely protection, DC input under voltage,over voltage, overload, short circuit, over temperature

Certifications

Detailed Images
