2014 Hot sell biodiesel machiery
Biodiesel, which has remarkable advantages in the aspect of environmental protection and reproducibility, is a replacement fuel made from renewable sources. As a substitution of fossil fuels, biodiesel has broad prospects with fossil fuels exhausting and global warming ,the biodiesel not only can be used for biofuel , it also can be as diesel fuel additive
specifications
Specifications: 5T/D---200T/D
The equipment is used to chemical industry field, raw material can be plant oil,animal oil,catering waste oil, acid oil etc..
It contains the international advanced pre-processing section, esterification process and distillation process, and it meets the European Union Standards,
The prodution steps are as follows:
1. Preprocessing section of bio-oil: when heated to 65-70°C, bio-oil is leached to remove impurities.
2. Drying section: bio-oil without impurities is dehydrated and dried.
3. First esterification reaction: adding bio-oil dehydrated to methanol including 3% sulfuric acid, first esterification reaction starts, and it will take 1.5—2.5 hours.
4. Second esterification reaction: this esterification reaction will take 9—12 hours.
5. Vacuum drying section: Second esterification reactants are dried with vacuum, removing moisture, reducing water content below 3%.
6. Distillation section: with vacuum state, second esterification reactants after vacuum drying section are heated to 220°C, biodiesel forms by steaming. Then cooling biodiesel to be liquid, the liquid biodiesel is just finished biodiesel.
7. Methanol fine-distillation: after biodiesel is isolated, the remaining methanol liquid is distilled to form methanol. Methanol cooled can be reused.
Bio-oil can be plant oil, animal oil or high acid-value waste oil.
The prodution steps are as follows:
PACKING
1.small equipments can be packed in wooden case and put into containers.
2.bigger equipments can be put into container naked packing, very safe.
3.very big equipments can be put in bulk vessel, it could contain goods of over 100tons, unit volume can be over 600m3.
4.we have a lot of experience of shipping big equipments to Brazil, Argentina, India, South Africa, USA, Canada Etc
SHIPPING
60 days after we received the downpayment
1 Tracking service for products for two years, lifetime warranty
2 Maintain and replacement service
3 Reminding for the service life of wearing parts/ paid to offer
4 oversea sales are available, installation guide for customer from both china and abroad.
5 Whole process install, guide, training from our engineer
zhong zhi yuan grain and oil machinery Co.,Ltd
