spindle and spindleless venner peeling machine
Main advantages
1 .An advanced CNC system ensures the veneers cut uniformly with a thickness tolerance of ± 0.05mm and width tolerance of ± 2.5mm.
2. Adjustable knife settings allow you to easily process logs larger in diameter and still produce smooth and flat finished veneers.
3.A user-friendly interface helps the operators spot any problems.
4. Even during rotary peeling, operators can still adjust for two different veneer thickness Without sacrificing the quality of either the peeling or cutting process.
5. A two-in-one structure, peeling and cutting together, reduces both the space and operators.Your costs is greatly lowered.
JINLUN CNC Spindleless Veneer Peeling Machine | |||
Type |
4 feet (1300mm) |
8 feet (2600mm) |
10 feet (3200mm) |
Model |
WWXQ130SY-40F |
WWXQ260SY-45F |
WWXQ320SY-50F |
Cutting Size |
450*1300mm |
450*2600mm |
500*3200mm |
(Diameter*Length) | |||
Min Residual |
28mm |
35mm |
35mm |
Diameter | |||
Max Stroke of |
400mm |
450mm |
500mm |
Tool Slide | |||
Cutting Thickness |
0.5~3.6mm |
0.5~3.6mm/3.6-6.5mm |
0.5~3.6mm |
Cutting Speed |
48m/min |
48m/min |
48m/min |
Power |
21.5KW |
31.5 KW |
45 KW |
Peeler blade |
1400mm*180mm*16mm |
2700mm*180mm*16mm |
3300mm*180mm*16mm |
(L*W*H) | |||
Clipper Size |
1400mm*90mm*12.7mm |
2700mm*90mm*12.7mm |
3300mm*90mm*12.7mm |
(L*W*H) | |||
Dimensions |
3200mm*2100mm*1350mm |
5300mm*2200mm*1450mm |
6800mm2200mm1450mm |
(L*W*H) | |||
Total Weight |
About3400KG |
About 7800KG |
About 12000KG |
Automatic Standard Veneer product Line
The Jinlun machinery Co., ltd was initiated and established since 1999 by our general manager Mr Li, We specialize in manufacturing woodworking peeling machinery . It has earned more than 20 national patents and formed a whole series of high-technique equipments and a completely set of production line ,such as 4 feet ,8 feet ,10 feet of peeling machine for spindle and spindleless. We areone of the largest professional manufactures factory in China .
Welcome to visit our company for cooperation.
